Tire pressure monitoring circuit, w/ advanced keyless entry & start system for Mazda 3 MPS II facelift (2011-2013)
Tire pressure monitoring circuit, w/ advanced keyless entry & start system
BLK WIRE
BRN WIRE
BUZZER
C-02
C-03
COMPUTER DATA LINES SYSTEM
ESCL FUSE
FUSE BLOCK
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
J/C C-44
J/C C-45
J/C C-53
KEYLESS CONTROL MODULE
KEYLESS RECEIVER/ TPMS CONTROL MODULE
LT BLU WIRE
MICROCOMPUTER
ORG/ WIRE
RED WIRE
RELAY & FUSE BLOCK
ROOM FUSE
TPMS IND TRIPMETER SWITCH
WHT WIRE
