Forced entry circuit, w/ advanced keyless entry & start system for Mazda 3 MPS II facelift (2011-2013)

BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE C-03 C-04 C-20 C-24 C-28 C-29 C-39 CENTER REAR OF LUGGAGE COMPT) COIL ANTENNA COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM D LOCK FUSE ENG+B FUSE FUSE BLOCK GRN WIRE HEATER FUSE HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED J/C C-43 J/C C-44 J/C C-47 J/C C-51 J/C C-53 KEY REMINDER SWITCH KEYLESS BEEPER KEYLESS CONTROL MODULE LEFT "C" PILLAR) LEFT FRONT EXTERIOR KEYLESS ANTENNA LEFT FRONT OUTER HANDLE LT BLU WIRE LT GRN WIRE MAIN RELAY METER FUSE MIRROR FUSE NCA WIRE ORG/ WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE REAR EXTERIOR KEYLESS ANTENNA REAR INTERIOR KEYLESS ANTENNA RED WIRE RELAY & FUSE BLOCK RELAY ENERGIZED REQUEST SWITCH REQUEST SWITCH (WAGON) ROOM FUSE SEDAN STARTING/CHARGING SYSTEM TRUNK LID LATCH, RELEASE ACTUATOR VIO WIRE WHT WIRE YEL WIRE

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE C-20 C-29 C-30 C-31 C-40 CLOSE CLOSE ON DOOR GRN WIRE GRN/ORG WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE HOOD LATCH SWITCH LEFT "C" PILLAR) LEFT DOOR LOCK SWITCH LEFT REAR DOOR LATCH, LOCK ACTUATOR (IN LEFT REAR DOOR) LIFTGATE LOCK ACTUATOR LIFTGATE OPENER SWITCH LOCK LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE RED WIRE RED/WHT WIRE REQUEST SWITCH RIGHT DOOR LOCK SWITCH RIGHT FRONT DOOR LATCH, LOCK ACTUATOR (IN FRONT PASSENGER'S DOOR) RIGHT FRONT EXTERIOR KEYLESS ANTENNA RIGHT FRONT OUTER HANDLE SEDAN TRUNK LID OPENER SWITCH UNLOCK VIO WIRE W/ DOOR LOCK-LINK SWITCH W/ THEFT- DETERRENT SYSTEM WAGON WHT WIRE YEL WIRE YEL/RED WIRE

ACC IND ACC RELAY AUTO RTN SW BLK WIRE BLU WIRE BRN WIRE BUZZER C-02 C-03 C-32 CLOSE COMPUTER DATA LINES SYSTEM DOOR DOOR IND FRONT INTERIOR KEYLESS ANTENNA GRN WIRE GRY WIRE GRY/BLU WIRE INSTRUMENT CLUSTER J/C C-45 J/C C-53 KEY IND KEYLESS CONTROL MODULE KEYLESS RECEIVER/ TPMS CONTROL MODULE LOCK LT BLU WIRE LT GRN WIRE MICROCOMPUTER NCA WIRE ON IND. ORG/ WIRE PNK WIRE POWER WINDOW RELAY PUSH BUTTON START RED WIRE RED/WHT WIRE RELAY BLOCK RIGHT REAR DOOR LATCH, LOCK ACTUATOR (IN RIGHT REAR DOOR) SECURITY IND SHIFT INTERLOCK SYSTEM STARTING/CHARGING SYSTEM STATUS (UR) IND STATUS (YG) IND UNLOCK VIO WIRE W/ DOOR LOCK-LINK SWITCH W/ THEFT- DETERRENT SYSTEM WHT WIRE WINDSHIELD WIPER RELAY YEL WIRE YEL/RED WIRE
