Car Wiring Diagrams for Charging circuit for Mazda 2 II facelift (2010-2014)

BATTERY BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU WIRE CHARGE INDICATOR COMPUTER DATA LINES SYSTEM FUSE BLOCK GENERATOR GRN/BLK WIRE HOT IN ON OR START HOT IN ON OR START METER (LEFT SIDE FUSE OF DASH) INSTRUMENT CLUSTER MAIN FUSE MAIN FUSE (IN RELAY & FUSE BOX) METER FUSE MICRO COMPUTER PCM PCM (LEFT SIDE OF ENGINE COMPT) RED WIRE STARTER STR FUSE WHT WIRE
