Power mirrors circuit for Mazda 2 II facelift (2010-2014)
Power mirrors circuit
BLK WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BRN/WHT WIRE
BRN/YEL WIRE
C-03
C-07
C-11
C-12
DEFOGGER SYSTEM
DOWN
FUSE BLOCK
FUSE BLOCK (LEFT SIDE
GRN/BLK WIRE
GRY/RED WIRE
GRY/WHT WIRE
HEATED OUTER MIRROR
HOT AT ALL TIMES
HOT IN ON OR ACC
LEFT
LEFT RIGHT UP
LEFT UP
LEFT UP/DOWN ADJUSTMENT MOTOR/ LEFT/RIGHT ADJUSTMENT MOTOR
LT GRN WIRE
LT GRN/BLK WIRE
MIRROR FUSE
P/W CM
P/W FUSE
P/W FUSE OF DASH)
POWER OUTER MIRROR SWITCH/ POWER WINDOW MAIN SWITCH
RIGHT
RIGHT UP/DOWN ADJUSTMENT MOTOR/ LEFT/RIGHT ADJUSTMENT MOTOR
UP LEFT RIGHT
