Car Wiring Diagrams for Horn circuit for Mazda 2 II facelift (2010-2014)

0922-202 0922-202 CLOCK SPRING 0922-203 AL C-02 BCM BCM (UNDER RIGHT SIDE OF DASH) BRN WIRE C-02 AL CLOCK- SPRING GRN WIRE HORN HORN (RIGHT FRONT OF ENGINE COMPT) HORN FUSE HORN RELAY HORN SWITCH HOT AT ALL TIMES NCA WIRE ORG/ WIRE RED WIRE RELAY & FUSE BOX RELAY & FUSE BOX (LEFT SIDE OF ENGINE COMPT) STOP FUSE VIO WIRE VIO/RED WIRE WHT WIRE
