Mazda 2 II facelift (2010-2014) temp hot ind Wiring diagrams
This page contains all the electrical diagrams for the component. temp hot ind, in which he is found in the car Mazda 2 II facelift (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram temp hot ind (1 of 2)
ABS IND.
AIR BAG IND
AMBIENT TEMPERATURE SENSOR
ANTI-THEFT SYSTEM
BEAM IND
BLK/ORG WIRE
BLU WIRE
BLU/RED WIRE
BRAKE IND
BRN/YEL WIRE
BUZZER
C-02
C-03
CAP IND
CHARGE IND
CHECK ENGINE (MIL) IND
CHECK FUEL
CHECK FUEL CAP IND
COMPUTER DATA LINES SYSTEM
CRUISE MAIN IND
CRUISE SET IND
DOOR IND
DOOR LOCKS SYSTEM
DRIVE CIRCUIT
DRIVE CIRCUIT SELECTOR INDICATOR
DSC IND
DSC OFF IND
EPS IND
F-01
FUSE BLOCK
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
LCD
LEFT TURN IND
LT GRN/YEL WIRE
MALFUNCTION IND
METER FUSE
METER FUSE (LEFT SIDE OF DASH)
MICRO COMPUTER
ODOMETER/ TRIPMETER, FUEL METER
OIL IND
OIL PRESSURE SWITCH
OIL PRESSURE SWITCH (BOTTOM LEFT SIDE OF ENGINE)
ORG/ WIRE
ORG/BLK WIRE
ORG/GRN WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RELAY & FUSE BOX
RELAY & FUSE BOX (LEFT SIDE OF ENGINE COMPT)
RIGHT TURN IND
ROOM FUSE
SEAT BELTS IND
SECURITY IND
SELECTOR INDICATOR
SOUND SYSTEMS
SOUND SYSTEMS DOOR LOCKS SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
SPEEDOMETER
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TEMP COOL IND
TEMP HOT IND
TPMS IND (IF EQUIPPED)
TRIPMETER SWITCH
VIO/WHT WIRE
WASHER IND (IF EQUIPPED)
WIPER/WASHER SYSTEM
YEL/GRN WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> TEMP HOT IND
Wiring diagram temp hot ind (2 of 2)
A/C FUSE
AMBIENT TEMPERATURE SENSOR
AMBIENT TEMPERATURE SENSOR (BEHIND LEFT SIDE OF
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/YEL WIRE
C-02
COMPUTER
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR
COOLING FAN MOTOR (LEFT FRONT OF ENGINE COMPT)
COOLING FAN RELAY 1
COOLING FAN RELAY 2
ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR 1
ENGINE COOLANT TEMPERATURE SENSOR 1 (RIGHT REAR OF ENGINE)
ENGINE COOLANT TEMPERATURE SENSOR 2
ENGINE COOLANT TEMPERATURE SENSOR 2 (LEFT FRONT CORNER OF ENGINE COMPT)
EVAPORATOR TEMPERATURE SENSOR
EVAPORATOR TEMPERATURE SENSOR (CENTER OF DASH)
FRONT FASCIA)
FUSE
FUSE BLOCK
FUSE BLOCK (LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/YEL WIRE
GRY WIRE
HIGH PRESSURE SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
LOW PRESSURE SWITCH
LT GRN/BLK WIRE
MEDIUM PRESSURE SWITCH
METER FUSE
MICRO -
MICRO COMPUTER
PCM
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
RED WIRE
RED/BLK WIRE
REFRIGERANT PRESSURE SWITCH
REFRIGERANT PRESSURE SWITCH (FRONT RIGHT OF ENGINE COMPT)
RELAY & FUSE BLOCK
RELAY & FUSE BLOCK (LEFT SIDE OF
TEMP HOT IND
WHT/RED WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Manual a/c circuit (2 of 2) -> TEMP HOT IND
