Car Wiring Diagrams for Blind spot information system circuit for Lincoln Navigator IV (2017-2022)

BATTERY JUNCTION BOX (BJB) BLIS INDICATOR BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DC TO DC CONVERTER CONTROL MODULE DRIVER DOOR MODULE (DDM) FUSE 15 FUSE 25 FUSE 26 GRN/VIO WIRE GRN/WHT WIRE GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED IGN OUT IGN SW SIG LEFT EXTERIOR MIRROR LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L) MS CAN + PASSENGER DOOR MODULE (PDM) POWER DISTRIBUTION SYSTEM RED WIRE RIGHT EXTERIOR MIRROR RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R) VBATT VIO/ORG WIRE VPWR YEL/RED WIRE YEL/VIO WIRE
