Car Wiring Diagrams for Electronic power steering circuit for Lincoln Navigator IV (2017-2022)

BATT + BATTERY JUNCTION BOX (BJB) BLK/VIO WIRE COMPUTER DATA LINES SYSTEM EPAS MOTOR FUSE 18 GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/ORG WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED INSTRUMENT PANEL CLUSTER (IPC) MEGA FUSE POWER STEERING CONTROL MODULE (PSCM) RUN/START WHT/GRN WIRE YEL/RED WIRE
