Lincoln Navigator IV (2017-2022) right front seat upper backrest horizontal motor Wiring diagram
This page shows the only wiring diagram for the component.right front seat upper backrest horizontal motor, which is found in the car Lincoln Navigator IV (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front seat upper backrest horizontal motor (1 of 1)
AFT
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FORWARD/
FUSE 26
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HALL EFFECT SENSE
HOT AT ALL TIMES
ILLUM
INCLINE
LEDS
LIN BUS
MS CAN +
PASSENGER DOOR MODULE (PDM)
PASSENGER SIDE FRONT REDUNDANT SEAT ADJUST SWITCH
POWER WINDOWS SYSTEM
RECLINE
RETURN
RIGHT FRONT SEAT CONTROL SWITCH
RIGHT FRONT SEAT HEADREST MOTOR ASSEMBLY
RIGHT FRONT SEAT REAR HEIGHT MOTOR
RIGHT FRONT SEAT UPPER BACKREST HORIZONTAL MOTOR
SEAT CONTROL MODULE B (SCMB)
SET 1
SET 2
SET 3
SIG
VBATT
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/ORG WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Passenger"s memory seat circuit (2 of 2) -> RIGHT FRONT SEAT UPPER BACKREST HORIZONTAL MOTOR
