Lincoln Navigator IV (2017-2022) nca Wiring diagrams

This page contains all the electrical diagrams for the component. nca, in which he is found in the car Lincoln Navigator IV (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram nca (51 of 98)

Wiring diagram nca for Lincoln Navigator IV (2017-2022) (51 of 98)

Get access

1 SPEED TRANSFER CASE 2 SPEED TRANSFER CASE BATTERY JUNCTION BOX (BJB) BLK/VIO WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CLUTCH COMPUTER DATA LINES SYSTEM DC TO DC CONVERTER CONTROL MODULE FUSE 13 FUSE 29 FUSE 32 FUSE 52 FUSE 63 FUSE 71 GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE HI TO LOW HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED INSTRUMENT PANEL CLUSTER (IPC) INTEGRATED WHEEL END SOLENOID IWE LOW TO HI MTR-CCW MTR-CW NCA WIRE POS 1 POS 1 MTR POS 2 POS 2 MTR POS 3 POS 3 MTR POS 4 POS 4 MTR POS RTN PWR IN PWR OUT RED WIRE RIGHT END OF DASH) TRANSFER CASE ASSEMBLY TRANSFER CASE CONTROL MODULE (TCCM) VBATT VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/RED WIRE VPWR W/ CENTER CONSOLE W/O CENTER CONSOLE WHT/GRN WIRE WHT/ORG WIRE WHT/RED WIRE

Go to component -> 4wd circuit -> NCA WIRE

Wiring diagram nca (52 of 98)

Wiring diagram nca for Lincoln Navigator IV (2017-2022) (52 of 98)

Get access

BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CLOCKSPRING COMPUTER COMPUTER DATA DATA LINES DC TO DC CONVERTER CONTROL MODULE DOOR LOCKS DOOR STATUS DOOR UNLOCK DOWNSHIFT PADDLE SWITCH FUSE 13 FUSE 52 GEAR SHIFT MODULE (GSM) GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) LINES SYSTEM NCA WIRE POWER DISTRIBUTION SYSTEM PWR IN PWR OUT RED WIRE SHIFT INTERLOCK OVERRIDE SWITCH SIGRTN SST-D SST-U STEERING COLUMN CONTROL MODULE (SCCM) SYSTEM TOWS TRANS CAN - UPSHIFT PADDLE SWITCH VBATT VIO WIRE VIO/BRN WIRE VIO/GRN WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component -> A/t circuit (2 of 3) -> NCA WIRE

Wiring diagram nca (53 of 98)

Wiring diagram nca for Lincoln Navigator IV (2017-2022) (53 of 98)

Get access

ATFPC ATFPM BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY/BRN WIRE GRY/ORG WIRE INTERMEDIATE SPEED SENSOR A (ISSA) INTERMEDIATE SPEED SENSOR B (ISSB) LINE PRESSURE CONTROL (LPC) SOLENOID NCA WIRE OUTPUT SHAFT SPEED (OSS) SENSOR PARK LOCK PAWL SOLENOID PWR SHIFT SOLENOID A SHIFT SOLENOID B SHIFT SOLENOID C SHIFT SOLENOID D SHIFT SOLENOID E SHIFT SOLENOID F TASV TORQUE CONVERTER CLUTCH (TCC) SOLENOID TRANSMISSION ASSEMBLY TRANSMISSION FLUID PUMP TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION RANGE (TR) SENSOR TURBINE SHAFT SPEED (TSS) SENSOR VIO WIRE VIO/GRN WIRE WHT/BLU WIRE WHT/VIO WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component -> A/t circuit (3 of 3) -> NCA WIRE

Wiring diagram nca (54 of 98)

Wiring diagram nca for Lincoln Navigator IV (2017-2022) (54 of 98)

Get access

A/D CHANNEL 2 A/D CHANNEL 3 A/D CHANNEL 4 A/D RETURN BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLK/GRY WIRE BLU WIRE BLU/BRN WIRE BRN/BLU WIRE CAN (+) CLOCKSPRING CNCL COMPUTER DATA LINES SYSTEM CRUISE CONTROL MODULE (CCM) DC TO DC CONVERTER CONTROL MODULE FUSE 15 FUSE 38 FUSE 52 GAP DOWN GAP UP GRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ PCM POWER RELAY ENERGIZED HOT W/ RUN/START RELAY ENERGIZED IGN SW SIG LEFT LOWER STEERING WHEEL SWITCH (NAVIGATOR) LEFT STEERING WHEEL SWITCH (EXPEDITION) NAVIGATION SYSTEM NCA WIRE OFF OUTPUT SHAFT SPEED (OSS) SENSOR POWER SPLY INPUT R/S OUTPUT RED WIRE RES+ RES/CNCL RIGHT STEERING WHEEL SWITCH SET- STEERING COLUMN CONTROL MODULE (SCCM) TRANSMISSION ASSEMBLY TRANSMISSIONS SYSTEM TURBINE SHAFT SPEED (TSS) SENSOR VBATT VPWR W/O ADAPTIVE CRUISE CONTROL W/ ADAPTIVE CRUISE CONTROL EXPEDITION NAVIGATOR WHT/VIO WIRE YEL/GRN WIRE YEL/ORG WIRE

Go to component -> Cruise control circuit (2 of 2) -> NCA WIRE

Wiring diagram nca (55 of 98)

Wiring diagram nca for Lincoln Navigator IV (2017-2022) (55 of 98)

Get access

BLK/WHT WIRE BLK/YEL WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE BRN/YEL WIRE CAN (-) CAN (+) COMPUTER DATA LINES SYSTEM DECKLID/ LIFTGATE RELAY FUSE 16 GRN/BLU WIRE GRN/WHT WIRE GRY/ORG WIRE GRY/RED WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) LIFTGATE APPLIQUE LIFTGATE GLASS ACTUATOR LIFTGATE GLASS AJAR LIFTGATE GLASS RELEASE LIFTGATE LATCH LIFTGATE RELEASE LIFTGATE RELEASE (FET) LIFTGATE RELEASE SWITCH MEGA FUSE MICRO - NCA WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE

Go to component -> Liftgate release circuit -> NCA WIRE

Wiring diagram nca (56 of 98)

Wiring diagram nca for Lincoln Navigator IV (2017-2022) (56 of 98)

Get access

A/D CHANNEL 1 A/D CHANNEL 2 A/D CHANNEL 3 A/D CHANNEL 4 A/D RTN AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE) BLK WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DM GND DM PWR DRAIN FRONT DISPLAY INTERFACE MODULE (FDIM) GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE LEFT FRONT DOOR MIDRANGE SPEAKER LF SPKR MID + LVDS (LOW-VOLTAGE DIFFERENTIAL SIGNALING) COAXIAL CABLE MIC - MICROPHONE (LEFT FRONT OF HEADLINER) NCA WIRE PWR STEERING COLUMN CONTROL MODULE (SCCM) TPA+ USB CABLE USB- HUB WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL/BLU WIRE

Go to component -> Navigation circuit, w/ touch screen (4 of 5) -> NCA WIRE

Wiring diagram nca (57 of 98)

Wiring diagram nca for Lincoln Navigator IV (2017-2022) (57 of 98)

Get access

BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE CINCH COMPUTER DATA LINES SYSTEM CONSOLE OPEN/CLOSE SW FRONT POWER LIFTGATE OPEN/CLOSE SWITCH FUSE 91 GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT LIFTGATE ANTI-PINCH SWITCH LIFTGATE REAR CONTROL SWITCH LIFTGATE RELEASE LIFTGATE/TRUNK MODULE (LTM) (LEFT "D" PILLAR) LT PINCH STRIP SIG MOTOR CLOSE, MOTOR OPEN, MS CAN + NCA WIRE PAWL SIG LIFTGATE GLASS AJAR PINCH STRIP RTN PRIMARY RATCHET SIG REAR INTERIOR SW RELEASE RIGHT LIFTGATE ANTI-PINCH SWITCH RT PINCH STRIP SIG SECONDARY RATCHET SIG SENSOR POWER SENSOR RTN SENSOR SIG 1 SENSOR SIG 2 UNCINCH VBATT VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE WHT/BLU WIRE WHT/VIO WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE ZERO POSITION SIG

Go to component -> Power liftgate circuit (1 of 3) -> NCA WIRE

Wiring diagram nca (58 of 98)

Wiring diagram nca for Lincoln Navigator IV (2017-2022) (58 of 98)

Get access

BLK/YEL WIRE BLU/BRN WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE INSTRUMENT PANEL CLUSTER (IPC) LIFTGATE LATCH/UNLATCH ASSEMBLY NCA WIRE PAWL/AJAR SW POSITION SENSOR PRIMARY RATCHET PWR MTR- RELEASE MTR RIGHT LIFTGATE DRIVE MOTOR ASSEMBLY (BASE OF RIGHT "D" PILLAR) SECONDARY RATCHET SENS POWER SENS RTN SENS SIG 1 SENS SIG 2 VIO/BRN WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/RED WIRE YEL/VIO WIRE ZERO POS

Go to component -> Power liftgate circuit (2 of 3) -> NCA WIRE

Wiring diagram nca (59 of 98)

Wiring diagram nca for Lincoln Navigator IV (2017-2022) (59 of 98)

Get access

BLK/VIO WIRE BLK/YEL WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/YEL WIRE CAN (-) CAN (+) COMPUTER DATA LINES SYSTEM FUSE 10 GRY/ORG WIRE HANDSFREE LIFTGATE ACTUATION MODULE HOT AT ALL TIMES ILLUMINATED LIFTGATE APPLIQUE LIFTGATE APPLIQUE LIFTGATE GLASS AJAR LIFTGATE GLASS RELEASE LIFTGATE RELEASE LIFTGATE RELEASE SWITCH MICRO - NCA WIRE OPEN SESAME INPUT OUTPUT VBATT VIO/WHT WIRE WHT WIRE WHT/BLU WIRE YEL/RED WIRE

Go to component -> Power liftgate circuit (3 of 3) -> NCA WIRE

Wiring diagram nca (60 of 98)

Wiring diagram nca for Lincoln Navigator IV (2017-2022) (60 of 98)

Get access

ACCUMULATOR PRESSURE GND BATTERY JUNCTION BOX (BJB) BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/WHT WIRE CLUTCH PRESSURE GND CLUTCH PRESSURE INPUT ACCUMULATOR PRESSURE INPUT COMPUTER DATA LINES SYSTEM DIFFERENTIAL CONTROL RELAY DIFFERENTIAL OIL TEMPERATURE SENSOR DIFFERENTIAL PRESSURE CONTROL VALVE DIFFERENTIAL PRESSURE SENSOR DIFFERENTIAL PUMP MOTOR FUSE 36 FUSE 54 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRY/BLU WIRE GRY/BRN WIRE HOT AT ALL TIMES HOT W/ PCM POWER RELAY ENERGIZED INSTRUMENT PANEL CLUSTER (IPC) MOTOR GND MOTOR SPLY NCA WIRE OIL TEMP SENS PRESSURE CONTROL VALVE HIGH SIDE PRESSURE CONTROL VALVE LOW SIDE PRESSURE SENS SPLY REAR DIFFERENTIAL CONTROL MODULE (DCMR) VPWR WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/GRN WIRE

Go to component -> Rear differential lock circuit -> NCA WIRE
