Lincoln Navigator IV (2017-2022) ms can + Wiring diagrams

BLK/GRY WIRE BLK/VIO WIRE BODY CONTROL MODULE (BCM) DATA LINK CONNECTOR (DLC) DRIVER DOOR MODULE (DDM) FUSE 12 FUSE 15 GATEWAY MODULE (LEFT SIDE OF DASH) GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE GRY/ORG WIRE HEADLAMP CONTROL MODULE (HCM) HEATED STEERING WHEEL MODULE HOT AT ALL TIMES MS CAN + POWER RUNNING BOARD (PRB) MODULE SIG GND TEST CONNECTOR TRAILER MODULE (TRM) VBATT VIO/ORG WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE

BATTERY ENERGY CONTROL MODULE B (BECMB) BLU WIRE DC TO DC CONVERTER CONTROL MODULE DRIVER MULTI-CONTOUR SEAT MODULE (SCMG) DRIVER SEAT MODULE (DSM) GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/ORG WIRE INSTRUMENT PANEL CLUSTER (IPC) LEFT "C" PILLAR) MICRO BODY CONTROL MODULE (BCM) MICRO PARKING AID MODULE (PAM) MS CAN + POWERTRAIN CONTROL MODULE (PCM) REAR DIFFERENTIAL CONTROL MODULE (DCMR) SYNC MODULE (APIM) TRANSMISSION CONTROL MODULE (TCM) VIO/ORG WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WIRELESS ACCESSORY CHARGING MODULE

AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE) AUDIO UNIT CD CHANGER FRONT CONTROLS INTERFACE MODULE (FCIM) GEAR SHIFT MODULE (GSM) GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/ORG WIRE HEAD-UP DISPLAY (HUD) MODULE LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L) LIFTGATE/ TRUNK MODULE (LTM) MS CAN + PASSENGER DOOR MODULE (PDM) PASSENGER MULTI-CONTOUR SEAT MODULE (SCMH) POWER FOLD MODULE (PFM) RADIO TRANSCEIVER MODULE (RTM) REAR AUDIO CONTROL MODULE (RACM) REAR ENTERTAINMENT MODULE (RETM) RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R) SEAT CONTROL MODULE B (SCMB) TELEMATICS CONTROL UNIT (TCU) MODULE VIO/ORG WIRE W/ HARMAN REVEL W/ TOUCH SCREEN WHT/GRN WIRE

ANTI-LOCK BRAKE SYSTEM (ABS) MODULE COLUMN, PEDAL MEMORY (BCMB) MODULE GRN/ORG WIRE GRY/BLU WIRE GRY/ORG WIRE IMAGE PROCESSING MODULE A (IPMA) MS CAN + OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) PARK ASSIST CAMERA MODULE POWER STEERING CONTROL MODULE (PSCM) REAR HVAC MODULE RESTRAINTS CONTROL MODULE (RCM) RIGHT END OF DASH) STEERING COLUMN CONTROL MODULE (SCCM) TRAILER BRAKE CONTROL (TBC) MODULE TRANSFER CASE CONTROL MODULE (TCCM) VEHICLE DYNAMIC MODULE (VDM) VIO/ORG WIRE

ANT BLK WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM FEEDBACK GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/ORG WIRE GRY/VIO WIRE ILLUM INSTRUMENT PANEL CLUSTER (IPC) KEYLESS VEHICLE FRONT ANTENNA KEYLESS VEHICLE FRONT FASCIA ANTENNA KEYLESS VEHICLE REAR ANTENNA LEFT FRONT DOOR HANDLE INTERIOR AMBIENT LIGHTING LAMP LOCK MS CAN + PASSENGER DOOR MODULE (PDM) PASSENGER DOOR WINDOW CONTROL SWITCH PWR RETURN RIGHT FRONT DOOR HANDLE INTERIOR AMBIENT LIGHTING LAMP RIGHT FRONT DOOR LOCK STATUS UNLOCK VBATT VIO WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/GRN WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/RED WIRE

ANT BLK WIRE BLK/GRY WIRE BLU WIRE BLU/GRN WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE (DDM) GRN/BRN WIRE GRN/VIO WIRE GRY WIRE GRY/ORG WIRE GRY/YEL WIRE HALF BRIDGE ILLUM KEYLESS VEHICLE SOUNDER LEDS LEFT FRONT DOOR LOCK LEFT FRONT SEAT CONTROL SWITCH LEFT REAR KEYLESS VEHICLE ANTENNA LIFTGATE GLASS RELEASE LIFTGATE RELEASE LOCK LOCK STATUS MASTER WINDOW CONTROL SWITCH MICRO - MS CAN + RED WIRE REMOTE KEYLESS ENTRY (RKE) EXTERIOR SOUNDER RETURN RIGHT REAR KEYLESS VEHICLE ANTENNA RTN UNLOCK VBATT VIO WIRE VIO/GRY WIRE VIO/ORG WIRE WHT WIRE YEL WIRE

BLIS INDICATOR BLK WIRE BLK/WHT WIRE BLU/GRN WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DRIVER DOOR MODULE (DDM) DRV MIRR MTR COM DRV MIRR MTR HORIZ DRV MIRR MTR VERT DRV PUDDLE DRV TURN ELECTROCHROMIC MIRROR CIRCUIT EXTERIOR REAR VIEW MIRROR SWITCH FOLD OUT FOLD-IN FUSE 23 FUSE 25 FUSE 26 GRN/BLU WIRE GRN/BRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT W/ ACCESSORY DELAY RELAY ENERGIZED LEFT EXTERIOR MIRROR LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED LEFT FRONT DOOR LOCK LEFT FRONT SEAT CONTROL SWITCH LEFT/RIGHT LIN BUS MASTER WINDOW CONTROL SWITCH MS CAN + PASS MIRR MTR COM PASS MIRR MTR HORIZ PASS MIRR MTR VERT PASS PUDDLE PASS TURN PASSENGER DOOR MODULE (PDM) PUDDLE RED WIRE RIGHT EXTERIOR MIRROR RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED RTN TURN UP/DOWN VBATT VIO/BRN WIRE VIO/GRN WIRE VIO/ORG WIRE VPWR WHT/GRN WIRE WHT/ORG WIRE YEL/RED WIRE YEL/VIO WIRE

A/D CHANNEL 1 A/D CHANNEL 2 A/D CHANNEL 3 A/D CHANNEL 4 A/D RTN BATTERY JUNCTION BOX (BJB) BLK/VIO WIRE BLU WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN/WHT WIRE BRN/YEL WIRE CLOCKSPRING (TOP OF STEERING COLUMN) COAX COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM FAMILY ENTERTAINMENT RELAY FAMILY ENTERTAINMENT SYSTEM FRONT CONTROLS INTERFACE MODULE (FCIM) FUSE 12 FUSE 23 FUSE 32 FUSE 46 GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT W/ ACCESSORY DELAY RELAY ENERGIZED MEDIA MS CAN + MUTE NCA WIRE PHONE DOWN PHONE UP PTT RIGHT STEERING WHEEL SWITCH SEEK STEERING COLUMN CONTROL MODULE (SCCM) VBATT VIO/GRN WIRE VIO/ORG WIRE VIO/RED WIRE VOL (-) VPWR WHT/BLU WIRE WHT/BRN WIRE

A/D CHANNEL 2 A/D CHANNEL 3 A/D CHANNEL 4 A/D RTN AUDIO BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BODY CONTROL MODULE (BCM) BRN/YEL WIRE CLOCKSPRING COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DISPLAY/ HUD FAMILY ENTERTAINMENT RELAY FAMILY ENTERTAINMENT SYSTEM FRONT CONTROLS INTERFACE MODULE (FCIM) FUSE 12 FUSE 23 FUSE 46 FUSE 9 GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT W/ ACCESSORY DELAY RELAY ENERGIZED LEDS MS CAN + NAV PHONE UP NCA WIRE PHONE SETTINGS DOWN REAR AUDIO CONTROL MODULE (RACM) RED WIRE RIGHT FRONT DOOR MIDRANGE SPEAKER RIGHT FRONT DOOR WOOFER SPEAKER RIGHT LOWER STEERING WHEEL SWITCH STEERING COLUMN CONTROL MODULE (SCCM) VBATT VIO/GRY WIRE VIO/ORG WIRE VPWR WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL/GRY WIRE

A/D CHANNEL 1 A/D CHANNEL 2 A/D CHANNEL 3 A/D CHANNEL 4 A/D RTN BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BODY CONTROL MODULE (BCM) BRN/YEL WIRE CLOCKSPRING (TOP OF STEERING COLUMN) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM FAMILY ENTERTAINMENT RELAY FAMILY ENTERTAINMENT SYSTEM FRONT CONTROLS INTERFACE MODULE (FCIM) FUSE 12 FUSE 23 FUSE 46 FUSE 9 GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT W/ ACCESSORY DELAY RELAY ENERGIZED MEDIA MS CAN + MUTE NCA WIRE PHONE DOWN PHONE UP PTT REAR AUDIO CONTROL MODULE (RACM) RED WIRE RIGHT STEERING WHEEL SWITCH SEEK STEERING COLUMN CONTROL MODULE (SCCM) VBATT VIO/ORG WIRE VOL (-) VPWR WHT/BLU WIRE WHT/GRN WIRE
