Lincoln Navigator IV (2017-2022) lamps on Wiring diagrams

This page contains all the electrical diagrams for the component. lamps on, in which he is found in the car Lincoln Navigator IV (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram lamps on (1 of 2)

Wiring diagram lamps on for Lincoln Navigator IV (2017-2022) (1 of 2)

Get access

AUTOLAMP AUTOLAMP ON BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN/BLU WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM EXPEDITION W/O HALOGEN FUSE 13 FUSE 15 FUSE 25 FUSE 76 GRN/ORG WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE H/L ON HAZARD HEAD/PARK HEADLAMP SWITCH HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY 1 INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY 2 LAMPS OFF LAMPS ON LEFT HEADLAMP ASSEMBLY LIN 6 LOW BEAM REQ MICRO - MULTI- FUNCTION SWITCH OFF PARK POWER DISTRIBUTION SYSTEM RED WIRE RIGHT HEADLAMP ASSEMBLY STEERING COLUMN CONTROL MODULE (SCCM) TURN TURN OUTAGE VBATT VIO/GRN WIRE WHT WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE

Go to component -> Exterior lamps circuit (1 of 5) -> LAMPS ON

Wiring diagram lamps on (2 of 2)

Wiring diagram lamps on for Lincoln Navigator IV (2017-2022) (2 of 2)

Get access

ANTI-LOCK BRAKE SYSTEM (ABS) MODULE AUTOLAMP AUTOLAMP ON BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLK/VIO WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DIM + ELECTRONIC PARK BRAKE SWITCH FRONT FOG FUSE 13 FUSE 25 FUSE 76 GRN/ORG WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE GRY/VIO WIRE H/L ON HDLP LEVELING HEAD/PARK HEADLAMP SWITCH HILL OUT HOT AT ALL TIMES ILLUM LAMPS OFF LAMPS ON LOW BEAM REQ MICRO - MULTI- FUNCTION SWITCH OFF PARK POWER DISTRIBUTION SYSTEM RED WIRE STEERING COLUMN CONTROL MODULE (SCCM) VBATT VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/VIO WIRE

Go to component -> Headlights circuit (1 of 4) -> LAMPS ON

Lincoln Navigator IV (2017-2022) lamps on Wiring diagrams

Wiring diagram lamps on (1 of 2)

List of components:

Wiring diagram lamps on (2 of 2)

List of components:
