Lincoln Navigator III (2006-2014) Rear camera circuit

1 2 3 4 5 6 VPWR VIDEO SHIELD ACCESSORY DELAY RELAY AUDIO CONTROL MODULE (ACM) (FRONT OF CONSOLE) BLK WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/VIO WIRE COMP+ CONTROL EC DRV- FUSE 35 FUSE 41 GRN/BRN WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN START OR RUN INSTRUMENT CLUSTER SYSTEM LT GRN WIRE MIRRORS SYSTEM NCA WIRE ORG/ WIRE REAR VIEW CAMERA DISPLAY MIRROR REVERSE SMART JUNCTION BOX (SJB) (BEHIND RIGHT KICK PANEL) TAN WIRE VIDEO CAMERA VIDEO+ VIDEO+ VIDEO- GND VPWR W/ NAVIGATION W/O NAVIGATION WHT/GRN WIRE YEL WIRE YEL/GRY WIRE
