Lincoln Navigator II (2002-2006) Warning systems circuit

19 (OR 505) BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/LT BLU WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL) DATA LINK CONNECTOR (DLC) DOOR AJAR IND 18 7 6 15 DRIVER SAFETY BELT BUCKLE SWITCH (IN DRIVER SAFETY BELT BUCKLE ASSEMBLY) DRIVER SIDE REAR DOOR AJAR SWITCH (AT REAR OF LEFT REAR DOOR) FUSE 1 FUSE 102 FUSE 15 FUSE 21 GRY/ORG WIRE HOT AT ALL TIMES HOT IN RUN OR ACC HOT IN START OR RUN IGNITION SWITCH INSTRUMENT CLUSTER KEY IN LEFT FRONT DOOR AJAR SWITCH (AT REAR OF LEFT FRONT DOOR) LIFTGATE GLASS ACTUATOR (IN LIFTGATE) LT BLU WIRE LT BLU/BLK WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/VIO WIRE MAIN LIGHT SWITCH MESSAGE CENTER SWITCH NCA WIRE ORG/ WIRE PASSENGER SIDE REAR DOOR AJAR SWITCH (AT REAR OF RIGHT REAR DOOR) PNK WIRE POWER LIFTGATE MODULE (AT LEFT SIDE OF CARGO AREA, BEHIND TRIM) RED WIRE RED/YEL WIRE RESTRAINTS CONTROL MODULE (BELOW CENTER CONSOLE) SAFETY BELT IND VEHICLE SECURITY MODULE (VSM) (UNDER RIGHT SIDE OF DASH) VIO WIRE VIO/WHT WIRE W/ POWER LIFTGATE W/O POWER LIFTGATE WHT WIRE WHT/VIO WIRE YEL WIRE
