Back-up lamps circuit for Lincoln Navigator I (1997-2003)
Back-up lamps circuit
BLK WIRE
BLK/PNK WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DIGITAL TRANSMISSION RANGE SENSOR (ON LEFT SIDE OF AUTOMATIC TRANSMISSION)
EXTERIOR LAMPS (TRAILER TOW BACK-UP LAMP RELAY)
FUSE 5
HOT IN RUN
LEFT REVERSING LAMP
LT BLU WIRE
MIRRORS SYSTEM (W ELECTRO- CHROMIC REAR VIEW ONLY)
NAVIGATION SYSTEM MODULE (FRONT CENTER OF CONSOLE)
PARKING AID MODULE (RIGHT REAR OF VEHICLE)
PNK WIRE
REMOTE ANTI-THEFT PERSONALITY MODULE (BEHIND LEFT SIDE OF DASH)
RIGHT REVERSING LAMP
