Car Wiring Diagrams for Electric parking brake circuit for Lincoln Nautilus I (2018-2024)

ANTI-LOCK BRAKE SYSTEM (ABS) MODULE BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 87 GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY/BLU WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) LEFT PARKING BRAKE ACTUATOR MOTOR MTR A EPB LT MTR A EPB RT MTR B EPB LT MTR B EPB RT NCA WIRE PARKING BRAKE SWITCH RIGHT PARKING BRAKE ACTUATOR MOTOR VBATT VIO/GRN WIRE VIO/GRY WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL/GRY WIRE
