Car Wiring Diagrams for Rear heated seats circuit for Lincoln Nautilus I (2018-2024)

BATTERY JUNCTION BOX (BJB) BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/ORG WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) DRV BATT DRV HIGH SW FUSE 36 FUSE 73 GRN WIRE GRN/BRN WIRE GRY/BRN WIRE HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED ILLUM LED LEFT HIGH IND LEFT LOW IND LEFT REAR SEAT BACKREST HEATER MAT LEFT REAR SEAT CUSHION HEATER MAT LEFT SWITCH LR HEATER FD LR SEAT NTC NCA WIRE PASS BATT PASS HIGH IND PASS HIGH SW PASS LOW IND REAR HEATED SEAT MODULE REAR HEATED SEAT SWITCH RED WIRE RETURN RIGHT HIGH IND RIGHT LOW IND RIGHT REAR SEAT BACKREST HEATER MAT RIGHT REAR SEAT CUSHION HEATER MAT RIGHT SWITCH RR HEATER FD RR HIGH/OFF RR LOW/OFF RR SEAT NTC VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VPWR WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE
