Lincoln Nautilus I (2018-2024) sdar drdl rx - Wiring diagram
This page shows the only wiring diagram for the component.sdar drdl rx -, which is found in the car Lincoln Nautilus I (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sdar drdl rx - (1 of 1)
AUDIO FRONT CONTROL MODULE (ACM)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BT MOD DRDL RX -
COAX
COAX TPA + COAX DM PWR COAX TPA - COAX DM GND
COMPUTER DATA LINES SYSTEM
DM GND
DM PWR
FRONT DISPLAY INTERFACE MODULE (FDIM)
FUSE 15
GPS
GRN/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LVDS (LOW-VOLTAGE DIFFERENTIAL SIGNALING) COAXIAL CABLE
MIC -
MICROPHONE
MS CAN +
MS CAN - (PINS: 43 TO 50 NOT USED) 51
NAVIGATION SYSTEM
NCA WIRE
RADIO CIRCUIT
SDAR DRDL RX -
SDAR DRDL TX -
SHIELD
STEREO L+
STEREO R+
SYNC ALERT -
SYNC MODULE (APIM) (BEHIND CENTER OF DASH)
TPA+
UNIVERSAL SERIAL BUS (USB) PORT
USB CABLE
VBATT
VIDEO+
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/ORG WIRE
Go to component -> Sync radio circuit -> SDAR DRDL RX -
