Lincoln Nautilus I (2018-2024) drv knee feed Wiring diagram
This page shows the only wiring diagram for the component.drv knee feed, which is found in the car Lincoln Nautilus I (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv knee feed (1 of 1)
BLU WIRE
CLOCKSPRING
DRIVER AIR BAG (STEERING WHEEL)
DRIVER KNEE AIR BAG
DRV AIR BAG 1 FEED
DRV AIR BAG 1 RTN
DRV AIR BAG 2 FEED
DRV AIR BAG 2 RTN
DRV FRT CR SN FEED
DRV FRT CR SN RTN
DRV KNEE FEED
DRV KNEE RTN
GRN/BLU WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
LEFT FRONT IMPACT SEVERITY SENSOR
NCA WIRE
PASS AIR BAG 1 FEED
PASS AIR BAG 1 RTN
PASS AIR BAG 2 FEED
PASS AIR BAG 2 RTN
PASS AIR BAG VENT FEED
PASS AIR BAG VENT RTN
PASS FRT CR SN FEED
PASS FRT CR SN RTN
PASS KNEE FEED
PASS KNEE RTN
PASSENGER KNEE AIR BAG
RESTRAINTS CONTROL MODULE (RCM)
SHORTING BAR
STAGE 1
STAGE 2
VENT PASSENGER AIR BAG
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
VPWR
W/ ADAPTIVE STEERING
W/O ADAPTIVE STEERING
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (4 of 4) -> DRV KNEE FEED
