Lincoln Nautilus I (2018-2024) audio unit antenna amplifier Wiring diagrams
This page contains all the electrical diagrams for the component. audio unit antenna amplifier, in which he is found in the car Lincoln Nautilus I (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram audio unit antenna amplifier (1 of 6)
ACTIVE NOISE CONTROL MICROPHONE 1
ACTIVE NOISE CONTROL MICROPHONE 2
ACTIVE NOISE CONTROL MICROPHONE 3
AMBIENT
ANTENNA PWR (PINS: 3 TO 7 NOT USED) 8
AUDIO FRONT CONTROL MODULE (ACM)
AUDIO SHIELD
AUDIO UNIT ANTENNA AMPLIFIER
AUX OUT 1-
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
CNTR IP SPKR-
COAX
COAX AM/FM ANT
COAX SATELLITE
COMPUTER DATA LINES SYSTEM
ENABLE
FUSE 13
FUSE 3
FUSE 32
FUSE 5
FUSE 9
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
INSTRUMENT PANEL SPEAKER
LF AMBIENT NOISE 1 +
LF SPKR
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
LR SPKR
NCA WIRE
NOISE 1 +
NOISE 2 +
NOISE 3 +
PWR
RED WIRE
RF AMBIENT NOISE 2 -
RF SPKR
RR AMBIENT NOISE 3 -
RR SPKR
SATELLITE RADIO/ GPS ANTENNA
SPLITTER
SUBWOOFER, AMPLIFIER UNIT
VBATT
VIO/GRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit, 10 speakers (1 of 2) -> AUDIO UNIT ANTENNA AMPLIFIER
Wiring diagram audio unit antenna amplifier (2 of 6)
ACTIVE NOISE CONTROL MICROPHONE 1
ACTIVE NOISE CONTROL MICROPHONE 2
ACTIVE NOISE CONTROL MICROPHONE 3
AMBIENT
AMP EN 1
ANTENNA PWR (PINS: 3 TO 7 NOT USED) 8
AUDIO FRONT CONTROL MODULE (ACM)
AUDIO UNIT ANTENNA AMPLIFIER
BLK/GRY WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
COAX
COAX AM/FM ANT
COAX SATELLITE
COMPUTER DATA LINES SYSTEM
DRAIN
FUSE 13
FUSE 25
FUSE 3
FUSE 32
FUSE 4
FUSE 9
GPS
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/RED WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
LF AMBIENT NOISE 1 +
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
NCA WIRE
NOISE 1 +
NOISE 2 +
NOISE 3 +
PWR
REAR AUDIO CONTROL MODULE (RACM)
RED WIRE
RF AMBIENT NOISE 2 -
RR AMBIENT NOISE 3 -
SATELLITE RADIO/ GPS ANTENNA
SPLITTER
SYNC MODULE (APIM)
VBATT
VIO/ORG WIRE
VIO/RED WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit, 13 speakers (1 of 3) -> AUDIO UNIT ANTENNA AMPLIFIER
Wiring diagram audio unit antenna amplifier (3 of 6)
ACTIVE NOISE CONTROL MICROPHONE 1
ACTIVE NOISE CONTROL MICROPHONE 2
ACTIVE NOISE CONTROL MICROPHONE 3
AMBIENT
ANTENNA PWR (PINS: 3 TO 7 NOT USED) 8
AUDIO ENABLE
AUDIO FRONT CONTROL MODULE (ACM)
AUDIO UNIT ANTENNA AMPLIFIER
BLK/GRY WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
COAX
COAX AM/FM ANT
COAX SATELLITE
COMPUTER DATA LINES SYSTEM
DRAIN
FUSE 13
FUSE 25
FUSE 3
FUSE 32
FUSE 4
FUSE 9
GPS
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/RED WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
LF AMBIENT NOISE 1 +
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
NCA WIRE
NOISE 1 +
NOISE 2 +
NOISE 3 +
PWR
REAR AUDIO CONTROL MODULE (RACM)
RED WIRE
RF AMBIENT NOISE 2 -
RR AMBIENT NOISE 3 -
SATELLITE RADIO/ GPS ANTENNA
SPLITTER
SYNC MODULE (APIM)
VBATT
VIO/ORG WIRE
VIO/RED WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit, 19 speakers (1 of 4) -> AUDIO UNIT ANTENNA AMPLIFIER
Wiring diagram audio unit antenna amplifier (4 of 6)
ACTIVE NOISE CONTROL MICROPHONE 1
ACTIVE NOISE CONTROL MICROPHONE 2
ACTIVE NOISE CONTROL MICROPHONE 3
AMBIENT
ANTENNA PWR (PINS: 3 TO 7 NOT USED) 8
AUDIO FRONT CONTROL MODULE (ACM)
AUDIO SHIELD
AUDIO UNIT ANTENNA AMPLIFIER
AUX OUT 1-
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
CNTR IP SPKR-
COAX
COAX AM/FM ANT
COAX SATELLITE
COMPUTER DATA LINES SYSTEM
ENABLE
FUSE 13
FUSE 3
FUSE 32
FUSE 5
FUSE 9
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
INSTRUMENT PANEL SPEAKER
LF AMBIENT NOISE 1 +
LF SPKR
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
LR SPKR
NCA WIRE
NOISE 1 +
NOISE 2 +
NOISE 3 +
PWR
RED WIRE
RF AMBIENT NOISE 2 -
RF SPKR
RR AMBIENT NOISE 3 -
RR SPKR
SATELLITE RADIO/ GPS ANTENNA
SPLITTER
SUBWOOFER, AMPLIFIER UNIT
VBATT
VIO/GRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Radio circuit, 10 speakers (1 of 2) -> AUDIO UNIT ANTENNA AMPLIFIER
Wiring diagram audio unit antenna amplifier (5 of 6)
ACTIVE NOISE CONTROL MICROPHONE 1
ACTIVE NOISE CONTROL MICROPHONE 2
ACTIVE NOISE CONTROL MICROPHONE 3
AMBIENT
AMP EN 1
ANTENNA PWR (PINS: 3 TO 7 NOT USED) 8
AUDIO FRONT CONTROL MODULE (ACM)
AUDIO UNIT ANTENNA AMPLIFIER
BLK/GRY WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
COAX
COAX AM/FM ANT
COAX SATELLITE
COMPUTER DATA LINES SYSTEM
DRAIN
FUSE 13
FUSE 25
FUSE 3
FUSE 32
FUSE 4
FUSE 9
GPS
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/RED WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
LF AMBIENT NOISE 1 +
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
NCA WIRE
NOISE 1 +
NOISE 2 +
NOISE 3 +
PWR
REAR AUDIO CONTROL MODULE (RACM)
RED WIRE
RF AMBIENT NOISE 2 -
RR AMBIENT NOISE 3 -
SATELLITE RADIO/ GPS ANTENNA
SPLITTER
SYNC MODULE (APIM)
VBATT
VIO/ORG WIRE
VIO/RED WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Radio circuit, 13 speakers (1 of 3) -> AUDIO UNIT ANTENNA AMPLIFIER
Wiring diagram audio unit antenna amplifier (6 of 6)
ACTIVE NOISE CONTROL MICROPHONE 1
ACTIVE NOISE CONTROL MICROPHONE 2
ACTIVE NOISE CONTROL MICROPHONE 3
AMBIENT
ANTENNA PWR (PINS: 3 TO 7 NOT USED) 8
AUDIO ENABLE
AUDIO FRONT CONTROL MODULE (ACM)
AUDIO UNIT ANTENNA AMPLIFIER
BLK/GRY WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
COAX
COAX AM/FM ANT
COAX SATELLITE
COMPUTER DATA LINES SYSTEM
DRAIN
FUSE 13
FUSE 25
FUSE 3
FUSE 32
FUSE 4
FUSE 9
GPS
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/RED WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
LF AMBIENT NOISE 1 +
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
NCA WIRE
NOISE 1 +
NOISE 2 +
NOISE 3 +
PWR
REAR AUDIO CONTROL MODULE (RACM)
RED WIRE
RF AMBIENT NOISE 2 -
RR AMBIENT NOISE 3 -
SATELLITE RADIO/ GPS ANTENNA
SPLITTER
SYNC MODULE (APIM)
VBATT
VIO/ORG WIRE
VIO/RED WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Radio circuit, 19 speakers (1 of 4) -> AUDIO UNIT ANTENNA AMPLIFIER
