Lincoln MKZ II facelift (2016-2020) transfer case fluid temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.transfer case fluid temperature sensor, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transfer case fluid temperature sensor (1 of 1)
AMBIENT AIR TEMPERATURE (AAT) SENSOR
BATTERY JUNCTION BOX (BJB)
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FUSE 54
GENERATOR CURRENT SENSOR
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LPC
OSS +
SSA
SSB
SSC
SSD
SSE
TCC
TFT
TFT SIG RTN
TR 1
TR 2
TR 3
TR 4
TR GND
TRANSFER CASE FLUID TEMPERATURE SENSOR
TRS
TSPC
TSS
TSS/OSS
TSS/OSS VPWR
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (5 of 9) -> TRANSFER CASE FLUID TEMPERATURE SENSOR
