Lincoln MKZ II facelift (2016-2020) splice block 12 Wiring diagram

BACKLIGHTING IND BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRY WIRE BLU WIRE BLU/BRN WIRE BLU/ORG WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN WIRE DRV BATT RUN/START VPWR PASS BATT DRV HIGH SW EXCEPT HYBRID HYBRID FUSE 36 FUSE 73 GRN WIRE GRN/BRN WIRE GRY/BRN WIRE HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED LEFT HIGH IND LEFT LOW IND LEFT REAR SEAT BACKREST HEATER MAT LEFT REAR SEAT CUSHION HEATER MAT LEFT SW LR HTR FD GND LR SEAT NTC NCA WIRE PASS HIGH IND PASS HIGH SW PASS LOW IND REAR HEATED SEAT MODULE REAR SEAT HEATED SEAT SWITCH RED WIRE RETURN RIGHT HIGH IND RIGHT LOW IND RIGHT REAR SEAT BACKREST HEATER MAT RIGHT REAR SEAT CUSHION HEATER MAT RIGHT SW RR HIGH/OFF RR HTR FD RR LOW/OFF RR SEAT NTC SPLICE BLOCK 12 VIO WIRE VIO/ORG WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE
