Lincoln MKZ II facelift (2016-2020) shade close Wiring diagrams
This page contains all the electrical diagrams for the component. shade close, in which he is found in the car Lincoln MKZ II facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram shade close (1 of 2)
ACCESSORY DELAYED RELAY
BATTERY JUNCTION BOX (BJB)
BLK/WHT WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/YEL WIRE
CAN (+)
CLOSE
COMPUTER DATA LINES SYSTEM
DELAYED ACCY RELAY
DISCRETE VSPD (HB)
EXCEPT HYBRID
FUSE 1 72
FUSE 23 31
FUSE 85
GLOBAL
GRY/BRN WIRE
GRY/RED WIRE
HALF BRIDGE
HOT AT ALL TIMES
ID-LOW
IGN/DELAY ACC
K- BUS
M/ROOF CLOSE
M/ROOF OPEN
M/ROOF TILT
MICRO -
NCA WIRE
OVERHEAD CONSOLE
PANORAMIC ROOF OPENING PANEL ANTI-PINCH SWITCH
PANORAMIC ROOF OPENING PANEL PRIMARY MOTOR
PANORAMIC ROOF OPENING PANEL SECONDARY MOTOR
PANORAMIC ROOF OPENING PANEL SHIELD MOTOR
PULSE TRAIN (FET)
REV LPS (FET)
REV SIG
SENS GND
SHADE CLOSE
SHADE OPEN
TILT
VEH SPEED
VIO WIRE
VIO/BRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/ORG WIRE
Go to component -> Panoramic roof circuit -> SHADE CLOSE
Wiring diagram shade close (2 of 2)
