Lincoln MKZ II facelift (2016-2020) rf outer sens Wiring diagram
This page shows the only wiring diagram for the component.rf outer sens, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf outer sens (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/WHT WIRE
CENTER CONSOLE SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISABLE SW
FRONT CONTROLS INTERFACE MODULE (FCIM)
FUSE 67
GND FRONT
GRN WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
ILLUM
LEFT FRONT ACTIVE PARK ASSIST SENSOR
LEFT FRONT INNER PARKING AID SENSOR
LEFT FRONT OUTER PARKING AID SENSOR
LF AUTO PARK SENS
LF INNER SENS
LF OUTER SENS
MICRO -
MS CAN +
PARK AID IND (FET)
PARK AID SENS
RF AUTO PARK SENS
RF INNER SENS
RF OUTER SENS
RIGHT FRONT INNER PARKING AID SENSOR
RIGHT FRONT OUTER PARKING AID SENSOR
SOLID STATE
START/
START/STOP DISABLE SW
START/STOP ENABLE/
START/STOP)
STOP ENABLE
VIO WIRE
VIO/GRY WIRE
W/ AUTO PARKING W/O AUTO PARKING
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit, except hybrid (2 of 2) -> RF OUTER SENS
