Lincoln MKZ II facelift (2016-2020) pwr ground logic ground Wiring diagram
This page shows the only wiring diagram for the component.pwr ground logic ground, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr ground logic ground (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/WHT WIRE
CAN (+)
COMM
COMPUTER DATA LINES SYSTEM
FRT WIPER HI
FUSE 1 80
FUSE 13
FUSE 3
FUSE 75
FUSE 83 1
GRN WIRE
GRN/BLU WIRE
GROUND
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HYBRID EXCEPT HYBRID FUSION MKZ
INSTRUMENT PANEL CLUSTER (IPC) MODULE
LEFT FRONT WINDSHIELD WIPER MOTOR
LIN VPWR IGN
LOW WASHER FLUID WARNING INDICATOR SWITCH
LOW WASHER SW
MICRO -
MULTI- FUNCTION SWITCH
POWER DISTRIBUTION SYSTEM
PUMP
PWR GROUND LOGIC GROUND
RAIN SENSOR MODULE
RIGHT FRONT WINDSHIELD WIPER MOTOR
RUN/ ACC (FET)
STEERING COLUMN CONTROL MODULE (SCCM)
VBATT
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
VPWR
VPWR IGN
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WINDSHIELD WASHER PUMP
WIPER RELAY
YEL WIRE
YEL/GRY WIRE
Go to component -> Wiper/washer circuit -> PWR GROUND LOGIC GROUND
