Lincoln MKZ II facelift (2016-2020) presented direction Wiring diagram
This page shows the only wiring diagram for the component.presented direction, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram presented direction (1 of 1)
AJAR
AJAR SW SIG
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/YEL WIRE
CAN (+)
CINCH CLOSE
CINCHED
CINCHED DIRECTION
COMPT AJAR
COMPT SW
COMPUTER DATA LINES SYSTEM
DECKLID RELEASE SWITCH/LAMP ASSEMBLY
DECKLID/ LIFTGATE RELAY
FRONT LUGGAGE COMPARTMENT OPEN/CLOSE SWITCH
FUSE 16
FUSE 76
FUSE 80
FUSION
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HYBRID EXCEPT HYBRID
INSTRUMENT PANEL CLUSTER (IPC) MODULE
IP RELEASE
LAMP
LIFTGATE/ DECKLID
LUGGAGE
LUGGAGE COMPARTMENT LID LATCH
LUGGAGE COMPARTMENT LID POWER STRIKER MOTOR
MEGA FUSE 2
MICRO -
MOTOR
MOTOR PRESENTED
NCA WIRE
POWER STRIKER MODULE
PRESENTED
PRESENTED DIRECTION
STRIKER DN SW SIG
STRIKER UP SW SIG
VBATT
VIO WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLU WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Trunk release circuit, w/o power decklid -> PRESENTED DIRECTION
