Lincoln MKZ II facelift (2016-2020) prc ctrl Wiring diagram
This page shows the only wiring diagram for the component.prc ctrl, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram prc ctrl (1 of 1)
BATTERY ENERGY CONTROL MODULE (BECM) (LEFT SIDE OF LUGGAGE COMPT)
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CHARGE COOLING ACTUATOR
COMPUTER DATA
CONT PWR EN
CS RTN
CS VREF
CTRL
DCDC WKUP
ENS
FAN FB
FAN PWM
FEEDBACK
GRN WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEV PHEV
HIGH VOLTAGE BATTERY JUNCTION BOX
HIGH VOLTAGE TRACTION BATTERY TEMPERATURE SENSOR
HS CAN+
INT-
LINES SYSTEM
MC-CTRL
MICRO -
MOTOR
ORG/ WIRE
PRC CTRL
PWR GND
TEMP RTN
TEMP SIG
VBATT
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VPWR
WAKE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.0l hybrid (5 of 10) -> PRC CTRL
