Lincoln MKZ II facelift (2016-2020) pass seat ntc sense Wiring diagram
This page shows the only wiring diagram for the component.pass seat ntc sense, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass seat ntc sense (1 of 1)
AIR CONDITIONING SYSTEM
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/VIO WIRE
BLU/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRV HEATED SEAT ELEMENT
DRV HTR FEED
DRV SEAT NTC SENSE
FRONT CONTROL INTERFACE MODULE (FCIM)
FUSE 65
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT BACKREST HEATER
LEFT FRONT SEAT CUSHION HEATER
MKZ FUSION
MS CAN +
NCA WIRE
PASS HEATED SEAT ELEMENT
PASS HTR FEED
PASS SEAT NTC SENSE
RED WIRE
RETURN
RIGHT FRONT SEAT BACKREST HEATER
RIGHT FRONT SEAT CUSHION HEATER
VIO WIRE
VIO/ORG WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Front heated seats circuit -> PASS SEAT NTC SENSE
