Lincoln MKZ II facelift (2016-2020) parking actor sw Wiring diagrams
This page contains all the electrical diagrams for the component. parking actor sw, in which he is found in the car Lincoln MKZ II facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
parking actor sw wiring diagram (1 of 2)
AIR CONDITIONING, HEADLIGHTS SYSTEMS
AUTO LAMP SENSOR
AUTO LAMP SENSOR RTN
AUTOLAMP ON
BACK LIGHT (FET)
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
BSI (FET)
CLUTCH POS SW PEDAL
DIM +
DOOR LOCKS, ANTI-THEFT SYSTEMS
ENG SW
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
FOG LAMP ON
GRN WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HAZARD SW FOG LAMP ON
HEAD/PARK LAMPS OFF
HEADLIGHTS SYSTEM
HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS
HORN SW
HORNS SYSTEM
INTERIOR LIGHTS SYSTEM ENGINE CONTROLS SYSTEM
IP RELEASE SW
K LINE
LOW BEAM REQ
MICRO -
NAVIGATION SYSTEM
PARK AID
PARK AID IND (FET)
PARK LAMPS ON
PARKING ACTOR SW
POWER DISTRIBUTION SYSTEM
PRCT 2
PRT 2 ANTENNA HI (HB)
SHIFT INTERLOCK, TRANSMISSIONS SYSTEMS
START BUTTON (FET)
START/STOP)
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHITE LIGHT (FET)
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/ORG WIRE
Go to component -> Body control modules circuit, except hybrid (3 of 3) -> PARKING ACTOR SW
