Lincoln MKZ II facelift (2016-2020) ops eop Wiring diagram
This page shows the only wiring diagram for the component.ops eop, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ops eop (1 of 1)
2.0L HYBRID
2.0L TURBO
2.5L, 2.5L FLEX FUEL
2.7L TURBO, 3.0L TURBO
A/D CHANNEL 1
A/D RETURN
AAT
AMBIENT AIR TEMPERATURE (AAT) SENSOR
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
DOWN
ENGINE CONTROLS SYSTEM
ENGINE OIL PRESSURE (EOP) SENSOR
ENGINE OIL PRESSURE SWITCH
FP PWR
FP RTN
FUEL LEVEL SENSOR
FUEL PUMP (FP) ASSEMBLY
FUEL PUMP CONTROL MODULE 1
FUSE 23
FUSION
FUSION EXCEPT HYBRID
FUSION MKZ
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
HOT IN RUN OR START
LEFT
LEFT STEERING WHEEL SWITCH (FUSION) LEFT UPPER STEERING WHEEL SWITCH (MKZ)
MKZ FUSION
NCA WIRE
OIL PRESSURE SWITCH
OPS EOP
ORG/ WIRE
PARKING BRAKE SWITCH
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
RIGHT
RIGHT STEERING WHEEL SWITCH (FUSION) RIGHT UPPER STEERING WHEEL SWITCH (MKZ)
S145 (2.0L TURBO) S150 (2.7L TURBO, 3.0L TURBO)
SIGRTN
STEERING COLUMN CONTROL MODULE (SCCM)
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VREF
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> OPS EOP
