Lincoln MKZ II facelift (2016-2020) open/close toggle sw shade close Wiring diagram
This page shows the only wiring diagram for the component.open/close toggle sw shade close, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram open/close toggle sw shade close (1 of 1)
ACCESSORY DELAYED RELAY
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/YEL WIRE
DEL/ACC
DELAYED ACCY RELAY
EXCEPT HYBRID
FUSE 31 23
FUSE 62
GRY/BRN WIRE
HOT AT ALL TIMES
MICRO -
NCA WIRE
OPEN/CLOSE TOGGLE SW SHADE CLOSE
OPEN/CLOSE TOGGLE SW SHADE CLOSE SHADE CLOSE
OVERHEAD CONSOLE
PANORAMIC ROOF OPENING PANEL SHIELD MOTOR
REAR WINDOW BLIND MODULE
RED WIRE
REV LPS (FET)
REV SIG
SHADE CLOSE
SHADE OPEN
VIO WIRE
W/O PANORAMIC ROOF W/ PANORAMIC ROOF HYBRID EXCEPT HYBRID
WHT WIRE
YEL WIRE
Go to component -> Rear window sun shade circuit -> OPEN/CLOSE TOGGLE SW SHADE CLOSE
