Lincoln MKZ II facelift (2016-2020) mirror fold in Wiring diagram
This page shows the only wiring diagram for the component.mirror fold in, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror fold in (1 of 1)
BLIS INDICATOR
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DEL ACCY
DRIVER DOOR MODULE (DDM)
DRIVER DOOR WINDOW CONTROL SWITCH
FUSE 25
FUSE 26
FUSE 31
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY DELAYED RELAY ENERGIZED
LEDS
LEFT EXTERIOR MIRROR
LEFT FRONT DOOR LOCK SWITCH
LEFT REAR DOOR MODULE (RDM)
MEM 1
MEM 2
MEM 3
MEM POS 1
MEM POS 2
MEM POS 3
MEMORY SET SWITCH
MIRROR FOLD IN
MIRROR FOLD OUT
MIRROR HEATING
MIRROR LEFT
MIRROR RTN
MIRROR SENSE SUPPLY
MIRROR SENSE X
MIRROR SENSE Y
MIRROR SENSOR/BLIS GND
MIRROR UP
MIRRORS SYSTEM
MS CAN +
NCA WIRE
ORG/ WIRE
ORG/WHT WIRE
PASSENGER DOOR MODULE (PDM)
PUDDLE LIGHT
RED WIRE
RIGHT EXTERIOR MIRROR
SIDE TURN INDICATOR
VBATT
VIO WIRE
VIO/GRN WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
