Lincoln MKZ II facelift (2016-2020) micro horn ctrl rly Wiring diagram
This page shows the only wiring diagram for the component.micro horn ctrl rly, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram micro horn ctrl rly (1 of 1)
BATTERY FUSE ASSEMBLY
BATTERY JUNCTION BOX (BJB)
BLK/GRN WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
CLOCKSPRING
FUSE 48
FUSION
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HORN
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
LEFT HORN
MICRO HORN CTRL RLY
MIDI FUSE (PINK)
NCA WIRE
RED WIRE
RIGHT HORN
STEERING COLUMN CONTROL MODULE (SCCM)
VIO WIRE
WHT WIRE
Go to component -> Horn circuit, hybrid -> MICRO HORN CTRL RLY
