Lincoln MKZ II facelift (2016-2020) led ntc sense Wiring diagram
This page shows the only wiring diagram for the component.led ntc sense, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram led ntc sense (1 of 1)
2.0L HYBRID
2.0L TURBO
2.5L, 2.5L FLEX FUEL
2.7L TURBO, 3.0L TURBO
AUTO
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BPP
BPS
BRN/YEL WIRE
FUSION
GRN/WHT WIRE
GRY WIRE
GRY/VIO WIRE
HEADLAMP SWITCH
HYBRID EXCEPT HYBRID
LED BIN SENSE
LED DRL/ PARK +
LED DRL/PARK+
LED NTC SENSE
LED SENSE
LEFT FRONT DRL/PARK LAMP
LEFT HEADLAMP ASSEMBLY
LIN GND
OFF
OUTAGE TURN
PARK
PARK LP
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RIGHT FRONT DRL/PARK LAMP
RIGHT HEADLAMP ASSEMBLY
SIDE MARKER
SIGRTN
STOP LAMP SWITCH
TURN GND
TURN LP
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit, w/o halogen headlamps (2 of 3) -> LED NTC SENSE
