Lincoln MKZ II facelift (2016-2020) hood ajar switch Wiring diagrams

This page contains all the electrical diagrams for the component. hood ajar switch, in which he is found in the car Lincoln MKZ II facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram hood ajar switch (1 of 4)

Wiring diagram hood ajar switch for Lincoln MKZ II facelift (2016-2020) (1 of 4)

Get access

1/2 3/4 5/6 7/8 9/0 AJAR AJAR SIG AJAR SW SIG BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLU/ORG WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM EXTERIOR SOUNDER FUSE 10 GRY WIRE GRY/BLU WIRE GRY/VIO WIRE HALF BRIDGE HOOD AJAR HOOD AJAR SWITCH HOT AT ALL TIMES KEYLESS ENTRY KEYPAD KEYPAD LOGIC LUGGAGE COMPARTMENT AJAR LUGGAGE COMPARTMENT LID LATCH MICRO - MS CAN + PROTECT 1 ANTENNA HI (HB) PROTECT 1 ANTENNA LO (HB) PROTECT 2 ANTENNA HI (HB) REAR GATE TRUNK MODULE RED WIRE SNDR VIO WIRE VIO/GRN WIRE W/ POWER LUGGAGE COMPARTMENT WHT WIRE WHT/GRN WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/RED WIRE

Go to component -> Anti-theft circuit (1 of 5) -> HOOD AJAR SWITCH

Wiring diagram hood ajar switch (2 of 4)

Wiring diagram hood ajar switch for Lincoln MKZ II facelift (2016-2020) (2 of 4)

Get access

2.0L TURBO 2.5L 2.5L FLEX FUEL 2.5L, 2.5L FLEX FUEL 2.7L TURBO, 3.0L TURBO ACTIVE GRILLE SHUTTER AIR CONDITIONING (A/C) COMPRESSOR AUDIO FRONT CONTROL MODULE (ACM) BATTERY BATTERY CURRENT SENSOR BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BLOWER MOTOR RELAY CABIN HEATER COOLANT PUMP COMPACT DISC PLAYER DATA LINK CONNECTOR (DLC) DIODE EXCEPT 2.7L TURBO, 3.0L TURBO 2.7L TURBO, 3.0L TURBO FRONT CONTROL/DISPLAY INTERFACE MODULE (FCDIM) FUEL INJECTOR HEATER CONTROL MODULE FUSION GATEWAY MODULE GLOBAL POSITIONING SYSTEM MODULE (GPSM) HOOD AJAR SWITCH LEFT FRONT FOG LAMP LEFT FRONT SIDE MARKER LAMP LEFT FRONT WINDSHIELD WIPER MOTOR LEFT HEADLAMP ASSEMBLY LEFT HORN LOW BRAKE FLUID WARNING INDICATOR SWITCH MULTI- CONTOUR SEAT RELAY NCA WIRE POWERTRAIN CONTROL MODULE (PCM) PROXIMITY WARNING RADAR UNIT REAR PARKING AID CAMERA RIGHT FRONT FOG LAMP RIGHT HORN STOP LAMP SWITCH SYNC MODULE (APIM) TRANSMISSION FLUID PUMP W/ ADAPTIVE CRUISE CONTROL W/ HALOGEN W/ SYNC 1 W/ SYNC 3 W/O SONY, TOUCH SCREEN WINDSHIELD WASHER PUMP

Go to component -> Ground distribution circuit, except hybrid (1 of 6) -> HOOD AJAR SWITCH

Wiring diagram hood ajar switch (3 of 4)

Wiring diagram hood ajar switch for Lincoln MKZ II facelift (2016-2020) (3 of 4)

Get access

AIR CONDITIONING CONTROL MODULE (ACCM) ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE BATTERY BATTERY CHARGER CONTROL MODULE (BCCM) BATTERY MONITORING SENSOR BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BRAKE VACUUM PUMP CABIN COOLANT HEATER CABIN HEATER COOLANT PUMP CHARGE PORT CHARGE PORT LIGHT RING COOLING FAN MODULE FUSION FUSION MKZ GRILLE SHUTTER ACTUATOR GRN/YEL WIRE HOOD AJAR SWITCH LEFT FRONT FOG LAMP LEFT FRONT SIDE MARKER LAMP LEFT FRONT WINDSHIELD WIPER MOTOR LEFT HEADLAMP ASSEMBLY LEFT HORN LOW BRAKE FLUID WARNING INDICATOR SWITCH LOW WASHER FLUID WARNING INDICATOR SWITCH MOTOR ELECTRONICS COOLANT SYSTEM PUMP (MECSP) MULTI- CONTOUR SEAT RELAY NCA WIRE POWER POINT RELAY 1 POWER POINT RELAY 2 POWERTRAIN CONTROL MODULE (PCM) PROXIMITY WARNING RADAR UNIT RESISTOR RIGHT FRONT FOG LAMP RIGHT FRONT SIDE MARKER LAMP RIGHT FRONT WINDSHIELD WIPER MOTOR RIGHT HEADLAMP ASSEMBLY RIGHT HORN TOP OF TRANSMISSION) TRANSMISSION FLUID PUMP TRANSMISSION RANGE CONTROL MODULE (TRCM) W/ HALOGEN WINDSHIELD WASHER PUMP

Go to component -> Ground distribution circuit, hybrid (1 of 5) -> HOOD AJAR SWITCH
