Lincoln MKZ II facelift (2016-2020) global positioning system module Wiring diagram
This page shows the only wiring diagram for the component.global positioning system module, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram global positioning system module (1 of 1)
2.7L TURBO
3.0L TURBO
ACCR
AIR CONDITIONING SYSTEM
AWDM
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/YEL WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BPP
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CACT
CANV
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
EVAPCP
FP PWR
FP RTN
FPC
FPM
FUEL
FUEL PUMP (FET)
FUEL PUMP ASSEMBLY 1
FUEL PUMP CONTROL MODULE 1 (BASE OF LEFT "C" PILLAR)
FUEL PUMP ON (FET)
FUEL PUMP RELAY
FUSE 58
FUSE 67
GENLI
GLOBAL POSITIONING SYSTEM MODULE
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
HFC/FCV
HOT AT ALL TIMES
IES
INSTRUMENT CLUSTER SYSTEM
ISP-R
LEFT "C" PILLAR)
LFC
MICRO -
PCM WAKEUP (FET)
POWERTRAIN CONTROL MODULE (PCM)
S165 (3.0L TURBO)
S415 (3.0L TURBO)
SIGRTN
SMC
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
TRANSMISSIONS SYSTEM
VACC
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
VREF
WAKEUP
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
WVS
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (1 of 9) -> GLOBAL POSITIONING SYSTEM MODULE
