Lincoln MKZ II facelift (2016-2020) fuse 60 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 60, in which he is found in the car Lincoln MKZ II facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 60 (1 of 6)
1.5L TURBO 2.0L TURBO 2.5L, 2.5L FLEX FUEL 2.7L TURBO, 3.0L TURBO
2.7L TURBO, 3.0L TURBO
AAT
ACCR
ACPT
AIR CONDITIONING (A/C) PRESSURE TRANSDUCER
AMBIENT AIR TEMPERATURE SENSOR
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
CHT
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR 1
COOLING FAN MOTOR 2
CYLINDER HEAD TEMPERATURE SENSOR
ECT
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
FUSE 59
FUSE 60
FUSE 63
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
HFC
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
LFC
NCA WIRE
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM)
PWM
SIG RTN
SIGRTN
VACC
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VREF
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, except hybrid (3 of 3) -> FUSE 60
Wiring diagram fuse 60 (2 of 6)
AAT
ACPT
AIR CONDITIONING (A/C) PRESSURE TRANSDUCER
AIR CONDITIONING CONTROL MODULE (ACCM)
AMBIENT AIR TEMPERATURE (AAT) SENSOR
BATTERY ENERGY CONTROL MODULE (BECM)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CABIN COOLANT HEATER (PHEV) (RIGHT REAR OF ENGINE COMPT)
CABIN HEATER COOLANT PUMP (PHEV) (FRONT OF ENGINE)
CHT
COMPUTER DATA LINES SYSTEM
COOLING FAN MODULE
CYLINDER HEAD TEMPERATURE (CHT) SENSOR
ELECTRIC MOTOR COOLANT PUMP
ENGINE CONTROLS SYSTEM
ENGINE COOLING FAN RELAY
FCV
FUSE 60
FUSE 8
GRILLE SHUTTER ACTUATOR (CENTER OF FRONT GRILLE)
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/VIO WIRE
HCSO
HEATER CORE SHUTOFF VALVE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HIGH VOLTAGE BATTERY SERVICE DISCONNECT
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
HV-
INT-
MEGA FUSE 5
ORG/ WIRE
ORG/BLK WIRE
ORG/WHT WIRE
POWERTRAIN CONTROL MODULE (PCM)
PWM
RED WIRE
SIGRTN
TCMRC
TOP OF TRANSMISSION)
VBATT
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VPWR
VREF
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, hybrid (3 of 3) -> FUSE 60
Wiring diagram fuse 60 (3 of 6)
1.5L TURBO 2.0L TURBO 2.5L, 2.5L FLEX FUEL 2.7L TURBO, 3.0L TURBO
2.7L TURBO, 3.0L TURBO
ACTIVE GRILLE SHUTTER
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
CHT
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR 1
COOLING FAN MOTOR 2
CYLINDER HEAD TEMPERATURE SENSOR
ECT
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR
FUSE 12
FUSE 59
FUSE 60
FUSE 63
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
HFC
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
LFC
NCA WIRE
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM)
SIGRTN
VIO WIRE
VIO/GRY WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Cooling fan circuit, except hybrid -> FUSE 60
Wiring diagram fuse 60 (4 of 6)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
BRN/GRN WIRE
CABIN HEATER COOLANT PUMP
CHT
COMPUTER DATA LINES SYSTEM
COOLING FAN MODULE
CYLINDER HEAD TEMPERATURE (CHT) SENSOR
ELECTRIC MOTOR COOLANT PUMP
ENGINE COOLING FAN RELAY
FCV
FUSE 12
FUSE 60
FUSE 8
GRILLE SHUTTER ACTUATOR (CENTER OF FRONT GRILLE)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HCHO
HEATER CORE SHUTOFF VALVE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
HS CAN+
MEGA FUSE 5
POWERTRAIN CONTROL MODULE (PCM)
PWM
RED WIRE
SIGRTN
VBATT
VIO WIRE
VIO/GRY WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Cooling fan circuit, hybrid -> FUSE 60
Wiring diagram fuse 60 (5 of 6)
2.5L, 2.5L FLEX FUEL
2.7L TURBO, 3.0L TURBO
2.7L TURBO, 3.0L TURBO 1.5L TURBO 2.0L TURBO 2.5L, 2.5L FLEX FUEL
A/C CLUTCH RELAY
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BACK LIGHT (FET)
BLOWER MOTOR RELAY
BLU WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BSI (FET)
COIL ON PLUG (COP) 1
COIL ON PLUG (COP) 2
COIL ON PLUG (COP) 3
COIL ON PLUG (COP) 4
COIL ON PLUG (COP) 5
COIL ON PLUG (COP) 6
DEMAND LP/ BATT SAVE RELAY
EXCEPT 2.5L, 2.5L FLEX FUEL MKZ FUSION
FROM FUEL PUMP RELAY (DIAGRAM 1 OF 7)
FROM FUSE 7 (DIAGRAM 1 OF 7)
FUSE 1
FUSE 11
FUSE 19
FUSE 20
FUSE 21
FUSE 25
FUSE 26
FUSE 37
FUSE 59
FUSE 60
FUSE 62
FUSE 64
FUSE 67
FUSE 68
FUSE 79
FUSE 84
FUSION
GRY WIRE
HEATED WINDSHIELD RELAY
HORN RELAY
IGNITION TRANSFORMER CAPACITOR
INT LTG (FET)
LEFT HEADLAMP ASSEMBLY
LF DRL LP (FET)
LF FOG LP (FET)
LF HIGH BEAM (FET)
LF LOW BEAM (FET)
LF POS LP (FET)
LF TURN LP (FET)
LR STOP POS LPS (FET)
LR TURN LP (FET)
ORG/ WIRE
PARK AID IND (FET)
PARK LPS (FET)
PCM WAKEUP (FET)
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
PROXIMITY WARNING RADAR UNIT
REAR WINDOW DEFROST RELAY
RED WIRE
REV LPS (FET)
RF DRL LP (FET)
RF FOG LP (FET)
RF HIGH BEAM (FET)
RF LOW BEAM (FET)
RF POS LP (FET)
RF TURN LP (FET)
RIGHT HEADLAMP ASSEMBLY
RR STOP POS LPS (FET)
RR TURN LP (FET)
RUN/ START RELAY
STARTER RELAY
STOP/ CHMSL (FET)
TO BODY CONTROL MODULE (BCM) (DIAGRAM 6 OF 7)
TO FUSE 23 (DIAGRAM 3 OF 7)
TO FUSE 53 (DIAGRAM 3 OF 7)
TORQUE VECTOR RELAY
TRANSMISSION FLUID PUMP
VIO WIRE
W/ ADAPTIVE CRUISE
WHITE LIGHT (FET)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (2 of 7) -> FUSE 60
Wiring diagram fuse 60 (6 of 6)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUTO PARK IND (FET)
BACK LIGHT (FET)
BATTERY CHARGER CONTROL MODULE (BCCM)
BATTERY ENERGY CONTROL MODULE (BECM)
BLOWER MOTOR RELAY
BLU WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BSI (FET)
COIL ON PLUG (COP) 1
COIL ON PLUG (COP) 2
COIL ON PLUG (COP) 3
COIL ON PLUG (COP) 4
DEMAND LP/ BATT SAVE RELAY
ENGINE COOLING FAN RELAY
FROM BODY CONTROL MODULE (BCM) (DIAGRAM 6 OF 7)
FROM FUEL PUMP (FP) RELAY (DIAGRAM 1 OF 7)
FROM FUSE 7 (DIAGRAM 1 OF 7)
FUSE 1
FUSE 11
FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 24
FUSE 25
FUSE 26
FUSE 35
FUSE 36
FUSE 59
FUSE 60
FUSE 62
FUSE 64
FUSE 67
FUSE 68
FUSE 79
GRN WIRE
GRY WIRE
HIGH VOLTAGE BATTERY CHARGER COOLING FAN
HIGH VOLTAGE BATTERY COOLING FAN
HORN RELAY
IGNITION TRANSFORMER CAPACITOR
INT LTG (FET)
LEFT HEADLAMP ASSEMBLY
LF DRL LP (FET)
LF FOG LP (FET)
LF HIGH BEAM (FET)
LF LOW BEAM (FET)
LF POS LP (FET)
LF TURN LP (FET)
LR STOP POS LPS (FET)
LR TURN LP (FET)
ORG/ WIRE
PARK AID IND (FET)
PARK LPS (FET)
PCM WAKEUP (FET)
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
PROXIMITY WARNING RADAR UNIT
REAR WINDOW DEFROST RELAY
RED WIRE
REV LPS (FET)
RF DRL LP (FET)
RF FOG LP (FET)
RF HIGH BEAM (FET)
RF LOW BEAM (FET)
RF POS LP (FET)
RF TURN LP (FET)
RIGHT HEADLAMP ASSEMBLY
RR PARK LPS (FET)
RR STOP POS LPS (FET)
RR TURN LP (FET)
RUN/ START RELAY
STOP/ CHMSL (FET)
TO FUSE 23 (DIAGRAM 3 OF 7)
TO FUSE 53 (DIAGRAM 3 OF 7)
TRANSMISSION FLUID PUMP
VACUUM PUMP CUT-OFF RELAY
VACUUM PUMP RELAY
VIO WIRE
W/ ADAPTIVE CRUISE
WHITE LIGHT (FET)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (2 of 7) -> FUSE 60
