Lincoln MKZ II facelift (2016-2020) fuse 43 Wiring diagram
This page shows the only wiring diagram for the component.fuse 43, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 43 (1 of 1)
BATTERY FUSE ASSEMBLY
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES SYSTEM
DOOR LOCK
FCIL
FFDUC
FUEL DOOR RELEASE RELAY
FUEL FILLER DOOR LATCH
FUEL FILLER DOOR RELEASE SWITCH
FUSE 13
FUSE 43
GRN WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
ILLUM
INSTRUMENT PANEL CLUSTER (IPC) MODULE
MICRO -
MIDI FUSE (PINK)
POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT)
PWR
PWR GND
RED WIRE
SIGRTN
TOP OF TRANSMISSION)
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Fuel door release circuit, hybrid -> FUSE 43
