Lincoln MKZ II facelift (2016-2020) fuel injector heater control module Wiring diagrams
This page contains all the electrical diagrams for the component. fuel injector heater control module, in which he is found in the car Lincoln MKZ II facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuel injector heater control module (1 of 2)
2.0L TURBO
2.5L
2.5L FLEX FUEL
2.5L, 2.5L FLEX FUEL
2.7L TURBO, 3.0L TURBO
ACTIVE GRILLE SHUTTER
AIR CONDITIONING (A/C) COMPRESSOR
AUDIO FRONT CONTROL MODULE (ACM)
BATTERY
BATTERY CURRENT SENSOR
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY
CABIN HEATER COOLANT PUMP
COMPACT DISC PLAYER
DATA LINK CONNECTOR (DLC)
DIODE
EXCEPT 2.7L TURBO, 3.0L TURBO 2.7L TURBO, 3.0L TURBO
FRONT CONTROL/DISPLAY INTERFACE MODULE (FCDIM)
FUEL INJECTOR HEATER CONTROL MODULE
FUSION
GATEWAY MODULE
GLOBAL POSITIONING SYSTEM MODULE (GPSM)
HOOD AJAR SWITCH
LEFT FRONT FOG LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT WINDSHIELD WIPER MOTOR
LEFT HEADLAMP ASSEMBLY
LEFT HORN
LOW BRAKE FLUID WARNING INDICATOR SWITCH
MULTI- CONTOUR SEAT RELAY
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM)
PROXIMITY WARNING RADAR UNIT
REAR PARKING AID CAMERA
RIGHT FRONT FOG LAMP
RIGHT HORN
STOP LAMP SWITCH
SYNC MODULE (APIM)
TRANSMISSION FLUID PUMP
W/ ADAPTIVE CRUISE CONTROL
W/ HALOGEN
W/ SYNC 1
W/ SYNC 3
W/O SONY, TOUCH SCREEN
WINDSHIELD WASHER PUMP
Go to component -> Ground distribution circuit, except hybrid (1 of 6) -> FUEL INJECTOR HEATER CONTROL MODULE
Wiring diagram fuel injector heater control module (2 of 2)
1.5L TURBO EXCEPT 1.5L TURBO
2.0L TURBO 2.5L, 2.5L FLEX FUEL
2.0L TURBO, 1.5L TURBO
2.0L TURBO, 2.7L TURBO, 3.0L TURBO
2.5L, 2.5L FLEX FUEL
2.5L, 2.5L FLEX FUEL 2.0L TURBO
2.7L TURBO, 3.0L TURBO
2.7L TURBO, 3.0L TURBO 1.5L TURBO
ACTIVE GRILLE SHUTTER
AIR CONDITIONING (A/C) COMPRESSOR CONTROL SOLENOID
ALL-WHEEL DRIVE (AWD) RELAY MODULE
BATTERY
BATTERY MONITORING SENSOR
BLU WIRE
BRN WIRE
CABIN HEATER COOLANT PUMP
CHARGE AIR COOLER (CAC) PUMP
EGR STEPPER MOTOR
EVAP CANISTER VENT VALVE
EVAP VAPOR BLOCKING VALVE
EVAPORATIVE EMISSION (EVAP) PURGE VALVE
EXCEPT 2.5L, 2.5L FLEX FUEL
FUEL INJECTOR HEATER CONTROL MODULE
FUEL PUMP RELAY
FUSE 12
FUSE 7
FUSE 8
FUSION
GENERATOR
GENERATOR CURRENT SENSOR
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/YEL WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
MEGA FUSE 2
MEGA FUSE 3
MEGA FUSE 4
MEGA FUSE 7
MEGA FUSE 8
NCA WIRE
OIL PRESSURE CONTROL SOLENOID
PCM POWER RELAY
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
STARTER MOTOR
TO BODY CONTROL MODULE (BCM) (DIAGRAM 4 OF 7)
TO BODY CONTROL MODULE (BCM) (DIAGRAM 6 OF 7)
TO DC TO DC CONVERTER CONTROL MODULE (DIAGRAM 7 OF 7)
TO FUSE 11 (DIAGRAM 2 OF 7)
TO FUSE 37 (DIAGRAM 2 OF 7)
TORQUE VECTOR RELAY
TRANSMISSION FLUID WARMER TEMPERATURE CONTROL VALVE
TURBO- CHARGER BYPASS VALVE (TCBY)
TURBO- CHARGER WASTEGATE REGULATING VALVE SOLENOID (TCWRVS)
VIO WIRE
W/O AUTO START/STOP SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (1 of 7) -> FUEL INJECTOR HEATER CONTROL MODULE
