Lincoln MKZ II facelift (2016-2020) etcrtn tss/oss/ tr gnd map sig rtn vacuum sens Wiring diagram
This page shows the only wiring diagram for the component.etcrtn tss/oss/ tr gnd map sig rtn vacuum sens, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram etcrtn tss/oss/ tr gnd map sig rtn vacuum sens (1 of 1)
BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CKP
CRANKSHAFT POSITION (CKP) SENSOR
ECT
ENGINE COOLANT TEMPERATURE (ECT) SENSOR
ETCREF
ETCRTN TSS/OSS/ TR GND MAP SIG RTN VACUUM SENS
FRP
FUEL RAIL PRESSURE (FRP) SENSOR
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/YEL WIRE
LPC
OPS
OSS +
OSS/TR GND
OSS/TR VPWR
POWERTRAIN CONTROL MODULE (PCM)
SIGRTN
SSA
SSB
SSC
SSD
SSE
TCBY
TCC
TCWRVS
TFT
TFT SIG RTN
TOP OF ENGINE)
TR-P
TRS
TSPC
TSS
TSS/GND
TSS/OSS TR VPWR
TSS/VPWR
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
VREF
WASTEGATE VACUUM SENSOR
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (6 of 6) -> ETCRTN TSS/OSS/ TR GND MAP SIG RTN VACUUM SENS
