Lincoln MKZ II facelift (2016-2020) driver temperature door actuator Wiring diagram
This page shows the only wiring diagram for the component.driver temperature door actuator, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver temperature door actuator (1 of 1)
AIR DISTRIBUTION DOOR ACTUATOR
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/VIO WIRE
BLOWER CONTROL
BLOWER MOTOR
BLOWER MOTOR CONTROL MODULE
BLOWER MOTOR RELAY
BLOWER RELAY
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DEFROST REQUEST
DRIVER TEMPERATURE DOOR ACTUATOR
DRV FRT SENS 1
DRV FRT SENS 2
DRV HEATER FEED
EVAP
FEEDBACK
FRONT CONTROLS INTERFACE MODULE (FCIM)
FUSE 12
FUSE 55
FUSE 65
FUSE 79
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
MOTOR
MS CAN +
ORG/ WIRE
PASS FRT SENS 1
PASS FRT SENS 2
PASS HEATER FEED
PASS ST NTC SENS
PASSENGER TEMPERATURE DOOR ACTUATOR
RED WIRE
SEATS SYSTEM
SIGRTN
TCM POWER RELAY
VBATT
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VREF
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Automatic a/c circuit, hybrid (1 of 3) -> DRIVER TEMPERATURE DOOR ACTUATOR
