Lincoln MKZ II facelift (2016-2020) brake booster travel sensor Wiring diagram
This page shows the only wiring diagram for the component.brake booster travel sensor, which is found in the car Lincoln MKZ II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake booster travel sensor (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/GRN WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BPP
BPS
BRAKE BOOSTER SOLENOID
BRAKE BOOSTER TRAVEL SENSOR
BRAKE VACUUM PUMP
BRK FLUID
BRN WIRE
BST PWM
BST PWR
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
FUSE 45
FUSE 47
FUSE 59
FUSION
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC) MODULE
LEVEL SWITCH
LOW BRAKE FLUID WARNING INDICATOR SWITCH
MICRO -
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH
POWERTRAIN CONTROL MODULE (PCM)
SIGRTN
STOP LAMP SWITCH
STOP LP SW
SYSTEM
VACUUM PUMP CUT-OFF RELAY
VACUUM PUMP RELAY
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, hybrid (2 of 2) -> BRAKE BOOSTER TRAVEL SENSOR
