Lincoln MKZ II (2012-2016) Rear window sun shade circuit, hybrid

1 2 3 4 5 6 7 8 9 10 OPEN/CLOSE TOGGLE SW ACCESSORY DELAY RELAY BATTERY JUNCTION BOX BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BODY CONTROL MODULE (LEFT END OF DASH) BRN WIRE DEL/ACC FUSE (LEFT SIDE OF ENGINE COMPT) FUSE 38 GRY WIRE GRY/BLU WIRE GRY/BRN WIRE HOT AT ALL TIMES MICRO - NCA WIRE OPEN/CLOSE TOGGLE SW OVERHEAD CONSOLE REAR WINDOW BLIND MODULE (LEFT SIDE OF LUGGAGE COMPT) RED WIRE REV LPS (FET) REV SIG SHADE CLOSE SHADE OPEN SPLICE BLOCK 14 (TOP OF RIGHT "A" PILLAR) VIO WIRE W/O PANORAMIC ROOF W/ PANORAMIC ROOF WHT WIRE
