Electrochromic mirror circuit, without rain sensor for Lincoln MKZ II (2012-2016)
Electrochromic mirror circuit, without rain sensor
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 RUN/START
AUTO DIMMING INTERIOR MIRROR
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
BRN WIRE
EC DRIVE
EC GND
FUSE 36
FUSION
HOT AT ALL TIMES
HOT IN RUN OR START
LEFT EXTERIOR MIRROR
MICRO -
REV LPS (FET)
REVERSE
WHT WIRE
YEL/GRY WIRE
