Electrochromic mirror circuit, except hybrid with rain sensor for Lincoln MKZ II (2012-2016)
Electrochromic mirror circuit, except hybrid with rain sensor
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 START/RUN
AUTO DIMMING INTERIOR MIRROR
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
BRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
EC DRIVE EC GND
FUSE 36
FUSION
GRN WIRE
GRY WIRE
HEATER
HOT IN RUN OR START
LEFT EXTERIOR MIRROR
MKZ FUSION
RAIN SENSOR MODULE (TOP CENTER OF WINDSHIELD)
VIO/WHT WIRE
YEL/GRY WIRE
