Electronic power steering circuit, hybrid for Lincoln MKZ II (2012-2016)
Electronic power steering circuit, hybrid
1 2 3 VPWR HS CAN + HS CAN -
1 2 PWR GND VBATT
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK/VIO WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRN/ORG WIRE
GRY/BLU WIRE
HIGH CURRENT BATTERY JUNCTION BOX
HOT AT ALL TIMES
HOT IN RUN OR START
MOTOR
POWER STEERING CONTROL MODULE (PSCM)
