Cooling fan circuit, except hybrid for Lincoln MKZ II (2012-2016)
Cooling fan circuit, except hybrid
1.6L TURBO 1.5L TURBO 2.0L TURBO 2.5L 3.7L
3 2 1 V PWR LIN GND
3.7L
50 4 23 50 4 23 50 4 23 55 18 34 55 18 34 LIN HFC LFC
ACTIVE GRILLE SHUTTER
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR 1 (BEHIND LEFT SIDE OF RADIATOR)
COOLING FAN MOTOR 2
ECT CHT SIG RTN 39 49 39 49
ENGINE CONTROLS SYSTEM
FAN CONTROL (FC) RELAY
FUSE
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
HIGH FAN CONTROL (HFC) RELAY
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
LOW FAN CONTROL (LFC) RELAY
ORG/ WIRE
POWERTRAIN CONTROL MODULE
VIO WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
