Lincoln MKZ II (2012-2016) universal heated oxygen sensor Wiring diagram
This page shows the only wiring diagram for the component.universal heated oxygen sensor, which is found in the car Lincoln MKZ II (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram universal heated oxygen sensor (1 of 1)
BATTERY
BATTERY FUSE ASSEMBLY
BATTERY MONITORING SENSOR
BLU WIRE
BRN WIRE
CABIN HEATER COOLANT PUMP
DC/DC CONVERTER MODULE (PHEV)
ELECTRIC ACTIVE MOTOR GRILLE COOLANT SHUTTER PUMP
ELECTRIC MOTOR COOLANT PUMP
ENGINE COOLING FAN RELAY
EVAPORATIVE EMISSION (EVAP) LEAK DETECTION CONTROL MODULE
EVAPORATIVE EMISSION (EVAP) VAPOR BLOCKING VALVE (HEV)
EVAPORATIVE FUEL EMISSION TANK (EVAP) ISOLATION PURGE VALVE (PHEV) VALVE
FUEL PUMP (FP) RELAY
FUSE
FUSE 12
FUSE 13
FUSE 14
FUSE 32
FUSE 7 TO FUSE 11 (DIAGRAM 2 OF 8)
GRN WIRE
GRY WIRE
HEATED ELECTRIC EXHAUST OXYGEN GAS RECIRCULATION SENSOR (EEGR) ASSEMBLY
HEATER CORE SHUT OFF (PHEV)
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
MASS AIR FLOW/ INTAKE AIR (MAF/IAT) TEMPERATURE SENSOR
MEGA FUSE 2
MEGA FUSE 3
MEGA FUSE 5
MEGA FUSE 6
MEGA FUSE 8
MIDI FUSE (PINK)
MIDI FUSE (WHITE)
NCA WIRE
NOT USED NOT USED
PCM POWER RELAY
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
SOLENOID
TO BODY CONTROL MODULE (BCM) (DIAGRAM 4 OF 8)
TO BODY CONTROL MODULE (BCM) (DIAGRAM 6 OF 8)
TO FUSE 37 (DIAGRAM 2 OF 8)
UNIVERSAL HEATED OXYGEN SENSOR
VACUUM PUMP RELAY
VARIABLE CAMSHAFT TIMING 11
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (1 of 8) -> UNIVERSAL HEATED OXYGEN SENSOR
