Lincoln MKZ II (2012-2016) start/stop dis sw start/ stop ind wiring diagram
This page shows the only wiring diagram for the component.start/stop dis sw start/ stop ind, which is found in the car Lincoln MKZ II (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
start/stop dis sw start/ stop ind wiring diagram (1 of 1)
2.0L 2.5L TURBO, 1.5L TURBO
2.0L TURBO 1.5L TURBO 1.6L TURBO 2.5L 3.7L
2.5L
2.5L 2.0L 1.5L TURBO
3.7L
39 1 36 10 22 32 10 22 32 TR-P TSS/OSS/ TRV PWR TSS/OSS /TR GND
AUTO FRONT CONTROL MODULE (ACM)
AUTO START STOP DEACTIVATION SWITCH
BATTERY
BLK WIRE
BLK/BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
DIS SW
ENG SW
FRONT CONTROLS INTERFACE MODULE (FCIM) (CENTER OF DASH)
FUSE
FUSE (LEFT END OF DASH)
GND SMCS TSS/OSS/ TR GND TR-1 TR-2 TR-3 TR-4
GRY/ORG WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
IGNITION SWITCH
MICRO -
MODULE (PCM) (RIGHT FRONT OF ENGINE)
MS CAN - MS CAN +
NCA WIRE
OFF
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL
PUSH BUTTON START/ STOP 1 IGNITION (ACTIVE SWITCH HIGH)
RED WIRE
RUN WIRE
SPLICE BLOCK 6 (UNDER CENTER CONSOLE)
START/STOP DIS SW START/ STOP IND
START/STOP)
STARTER MOTOR
STARTER RELAY
STOP IND START/
TR-P OSS/TR VPWR OSS/TR GND
TRANSMISSION (2.0L TURBO, 2.5L, 1.5L TURBO) (LEFT SIDE OF TRANSMISSION)
TRANSMISSION (3.7L) (LEFT SIDE OF TRANSMISSION)
TRANSMISSIONS SYSTEM
TRS
TRS 7 6 5 4 8 TR-4 TR-3 TR-2 TR-1 TR GND
VIO BRN/ WIRE
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ PUSH BUTTON
W/O PUSH BUTTON
WHT WIRE
WHT/ BLU WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Starting circuit -> START/STOP DIS SW START/ STOP IND
