powertrain control wiring diagram (1 of 3)
13 46 58 59 66 65 68 69 66 65 68 69 BPP BPS
2.5L 2.0L 1.6L 3.7L 1.5L TURBO TURBO TURBO
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK/BLU WIRE
BLK/GRN WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
BRK FLUID LEVEL SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
FUSION
GRN/BLU WIRE
GRN/VIO WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LOW BRAKE FLUID WARNING INDICATOR SWITCH (ON BRAKE FLUID RESERVOIR)
MICRO -
MODULE (PCM) (RIGHT FRONT OF ENGINE)
ORG/ WIRE
PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER ASSEMBLY)
POWERTRAIN CONTROL
STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY)
STOP LP SW
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
Go to component -> Anti-lock brakes circuit, except hybrid (2 of 2) -> POWERTRAIN CONTROL
powertrain control wiring diagram (2 of 3)
39 2 3 19 20 SIGRTN BPP BPS
4 3 BST PWM BST PWR
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK/BLU WIRE
BLK/GRN WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
BRAKE BOOSTER SOLENOID (LEFT REAR OF ENGINE COMPT)
BRAKE BOOSTER TRAVEL SENSOR (ON BRAKE BOOSTER)
BRAKE VACUUM PUMP
BRK FLUID LEVEL SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE COMPT)
FUSE
FUSION
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT PANEL CLUSTER (IPC)
LOW BRAKE FLUID WARNING INDICATOR SWITCH (ON BRAKE FLUID RESERVOIR)
MICRO -
MODULE (PCM) (RIGHT REAR OF ENGINE COMPT)
POWERTRAIN CONTROL
STOP LAMP SWITCH (UNDER LEFT SIDE OF DASH)
STOP LP SW
VACUUM PUMP CUT-OFF RELAY
VACUUM PUMP RELAY
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, hybrid (2 of 2) -> POWERTRAIN CONTROL
powertrain control wiring diagram (3 of 3)
2.0L 2.5L TURBO, 1.5L TURBO
2.0L TURBO 1.5L TURBO 1.6L TURBO 2.5L 3.7L
2.5L
2.5L 2.0L 1.5L TURBO
3.7L
39 1 36 10 22 32 10 22 32 TR-P TSS/OSS/ TRV PWR TSS/OSS /TR GND
AUTO FRONT CONTROL MODULE (ACM)
AUTO START STOP DEACTIVATION SWITCH
BATTERY
BLK WIRE
BLK/BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
DIS SW
ENG SW
FRONT CONTROLS INTERFACE MODULE (FCIM) (CENTER OF DASH)
FUSE
FUSE (LEFT END OF DASH)
GND SMCS TSS/OSS/ TR GND TR-1 TR-2 TR-3 TR-4
GRY/ORG WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
IGNITION SWITCH
MICRO -
MODULE (PCM) (RIGHT FRONT OF ENGINE)
MS CAN - MS CAN +
NCA WIRE
OFF
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL
PUSH BUTTON START/ STOP 1 IGNITION (ACTIVE SWITCH HIGH)
RED WIRE
RUN WIRE
SPLICE BLOCK 6 (UNDER CENTER CONSOLE)
START/STOP DIS SW START/ STOP IND
START/STOP)
STARTER MOTOR
STARTER RELAY
STOP IND START/
TR-P OSS/TR VPWR OSS/TR GND
TRANSMISSION (2.0L TURBO, 2.5L, 1.5L TURBO) (LEFT SIDE OF TRANSMISSION)
TRANSMISSION (3.7L) (LEFT SIDE OF TRANSMISSION)
TRANSMISSIONS SYSTEM
TRS
TRS 7 6 5 4 8 TR-4 TR-3 TR-2 TR-1 TR GND
VIO BRN/ WIRE
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ PUSH BUTTON
W/O PUSH BUTTON
WHT WIRE
WHT/ BLU WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Starting circuit -> POWERTRAIN CONTROL
